Instructions for installation and use

6. Assembling the cabin

ATTENTION!
The cabin is designed for both "right-hand" and "left-hand" assembly.
Please observe the floor plans on pages 10 and 11, depending on model.
Observe the figures starting on page 17.

6.1. Assembling the base frame

Screw the corners of the base frame in place as shown. When doing so, make
sure it is aligned horizontally (use spirit level). The gap between the floor and
the base frame at the front side must be no more than 5 mm.

6.2. Installing wall elements

Installation of the wall elements starts with the lower rear wall (ventilation ele-
ment). The corner post is first screwed flush with the lower rear wall. Next, the
upper rear wall is installed, and is screwed to the corner post.
Assemble the side walls and screw these to the corner posts.
The upper side walls are screwed to the lower side walls.
The lower side walls are screwed to the base frame.
Now move the sauna to its final position and check the right angles (see tip on
page 4).

6.3. Installing the glass frame

The corner posts with groove for glass are connected to the side walls using
Multiclips. Push the corner post down onto the wall element from above. When
doing this, ensure that the Multiclips and the groove for the glass are correctly
aligned. The corner post must be flush with the wall element.
Insert the element into the corner post above the door. Pay attention to the
alignment of the groove and the suspension fittings. Screw the element to the
corner posts.
On the electrical element, draw a vertical guideline for the position of the cable
shaft.

6.4. Roof installation

First insert the frontmost roof element and screw it to the element above the door.
Insert the remaining roof elements and screw them to the cabin walls. Observe
the cable outlets.
p. 12/16
