Sentiotec Fuji Montageanleitung Seite 7

Instructions for installation and use
No. of Name
items
Interior fittings
1 Upper bench – angled bench
1 Upper bench
1 Lower bench
1 Lower bench
1 Lower bench – angled bench
1 Bench foot
1 Bench foot
1 Floor grid
2 Headrest
1 Ventilation slit
Glass elements
1 Glass door, black
1 Glass element with holes for door hinges, black
1 Glass element, black
Accessories
1 Door handle set, black
1 2 door hinges 8652-02, black
1 Door magnet, sleeve plate, black
2 Aluminium U-profile, black
2 Spacers for glass
2 LED strips, integrated into bench
1 Installation material set
1 Assembly instructions
p. 7/16
Dimensions (cm)
69.5 x 62 x 13
185.3 x 62 x 13
185.3 x 62 x 9
123.3 x 35 x 13
72 x 62 x 13
62 x 91.5 x 6
62 x 49.5 x 6
58 x 41 x 4
43 x 26 x 7
56 x 14 x 1.5
198.5 x 68 x 0.8
201.8 x 56.3 x 0.8
201.8 x 56.3 x 0.8
90 x 7 x 4
10 x 4 x 0.3
185.3 x 2 x 1.6
