Specific conditions of use (for CCCEx)
Gas:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to GB/T 3836.1, taking into account the
environmental conditions under which the equipment is used.
• The equipment shall be installed in such a way that the risk of mechanical danger is low.
• The equipment shall only be used in an area of not more than pollution degree 2, as defined in GB/T 16935.1
• Provisions shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than
119 V.
Dust:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to GB/T 3836.31 for non-conductive dust and
IP6X, for conductive dust, taking into account the environmental conditions under which the equipment is used.
• The equipment shall be installed in such a way that the risk of mechanical danger is low.
• When installed in accordance with the service temperature as stated in table 1, a maximum temperature classification
of T70 ºC can be given.
Observe the following FAQ regarding the use of an HMI / IPC device in hazardous areas: ATEX-FAQ
(https://support.industry.siemens.com/cs/ww/en/view/291285)
WARNING
The device has to be used in pollution degree 2 environment only.
WARNING
Use copper supply wires of at least 1,3 mm
CAUTION
DC-Version
If a main circuit breaker for DC-supply should be installed in hazardous locations as described above it has to be intended
for use in that area. Otherwise it must be installed in an area which is known to be non-hazardous.
WARNING
Opening the device
DO NOT OPEN WHEN ENERGIZED.
WARNING
Risk of explosion when connecting or disconnecting the device
EXPLOSION HAZARD
WARNING – EXPLOSION HAZARD - Do not connect or disconnect while circuit is live unless area is known to be non-
hazardous.
WARNING
Explosion hazard from sparks when connectors come loose
If a plug connector comes loose from the associated device interface during operation in a hazardous area, a spark over at
the interface may cause an explosion. Death or serious physical injury as well as property damage may result.
For use in hazardous areas, it must be ensured that the plug connectors of the cables are fully connected to the respective
interface and cannot come loose from the interfaces in any case.
Secure all connected cables directly at the transition between connector and cable to the nearest fastening point of the
strain relief plate or strain relief element using a cable tie. Tighten up all cable ties in such a way that they fully wrap
around the respective cable but do not damage the cable.
WARNING
Explosion Hazard
Batteries must only be changed in an area known to be non-hazardous.
The lithium battery shall only be replaced by a trained technician.
SIMATIC IPC677E
A5E51211229-AD, 07/2023
or AWG 16.
