Approval marks
DEKRA 15ATEX 0119 X and / or IECEx DEK 15.0080X and/or DEKRA 21UKEX0209X for Gas
DEKRA 20ATEX0082 U and / or IECEx DEK 20.0041U and/or DEKRA 21UKEX0210U for Dust
UL - E-file number: E223122
Permissible ambient temperature during operation for devices with Ex marking
Vertical With SSD
Vertical, inclined With SSD
< ± 45°
Horizontal With SSD
Protection against foreign objects and water built-in devices
When mounted IP65
Specific conditions of use (for ATEX)
Gas:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to EN 60079-7, taking into account the
environmental conditions under which the equipment is used.
The equipment shall be installed in such a way that the risk of mechanical danger is low.
• The equipment shall only be used in an area of not more than pollution degree 2, as defined in EN 60664-1.
• Provisions shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than
119 V.
Dust:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to EN 60079-31 for group IIIA and IIIB and
IP6X according to EN 60079-31 for group IIIC, taking into account the environmental conditions under which the
equipment is used.
• The equipment shall be installed in such a way that the risk of mechanical danger is low.
• When installed in accordance with the service temperature as stated in table 1, a maximum temperature classification of
T70 ºC can be given.
Specific conditions of use (for IECEx)
Gas:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to IEC 60079-7, taking into account the
environmental conditions under which the equipment is used.
• The equipment shall be installed in such a way that the risk of mechanical danger is low.
• The equipment shall only be used in an area of not more than pollution degree 2, as defined in IEC 60664-1.
• Provisions shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than
119 V.
Dust:
The front side of the Industrial PC SIMATIC IPC677E provides a degree of protection of at least IP65. It shall be installed in a
suitable enclosure providing a degree of protection of at least IP54 according to IEC 60079-31 for non-conductive dust and
IP6X, for conductive dust, taking into account the environmental conditions under which the equipment is used.
• The equipment shall be installed in such a way that the risk of mechanical danger is low.
• When installed in accordance with the service temperature as stated in table 1, a maximum temperature classification of
T70 ºC can be given.
8
+0 to +45 °C
+0 to +40 °C
+0 to +45 °C
Enclosure Type 4X/12
SIMATIC IPC677E
A5E51211229-AD, 07/2023
