Function
Scanning effect 1
Scanning effect 2
Scanning effect 3
Scanning effect 4
Scanning effect 5
Effect speed
Strobe
Auto *
Sound control *
Slave / DMX
1 = on
0 = off
Internal Programs ~ Scanning effects 1 - 5
5 main programs and their variations can be selected by setting combinations of DIP switches 1-5 (see
above table).
Set DIP switch 1 to 5, depending upon the desired program, to ON and DIP switches 6 to10 to OFF.
Effect speed
In order to change the speed of a desired program, set DIP switch 6 to ON.
Strobe
For strobe effekt, set DIP switch 7 to ON.
Auto
( * = with mirror movement)
To select Auto Mode, set DIP switches 1 to 10 to OFF and DIP switch 8 to ON.
Sound Control
( * = with mirror movement)
To select sound control, set DIP switches 1 to 10 to OFF and DIP switch 9 to ON.
You can adjust the sensitivity with the rotary-control on the rearpanel.
Master / Slave
To determine the Master device, Set set DIP switch 1 to 9 to ON and DIP switch 10 to OFF.
To determine the Slave device, Set set DIP switch 1 to 9 to OFF and DIP switch 10 to ON.
DIP
DIP
DIP
DIP
1
2
3
4
1
0
0
0
0
1
0
0
0
0
1
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
DIP
DIP
DIP
DIP
5
6
7
8
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
1
0
0
0
0
1
0
0
0
0
1
0
0
0
0
0
0
0
0
20/24
DIP
DIP
Mode:
9
10
0
0
0
0
0
0
0
0
Auto (Master)
0
0
0
0
0
0
0
0
1
0
Sound control (Master)
1
0
Slave / DMX
