Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of DMX channels:
DMX-512 connection:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
LED Type:
Number of LEDs:
Dimensions (LxWxH):
Weight:
Accessories:
EUROLITE TH-51S Theatre hook, black
EUROLITE TH-50S Theatre hook, black
Saveking Safety bond 3x600 black
Saveking Safety bond 3x1000 black
Please note: Every information is subject to change without prior notice. 27.09.2012 ©
230 V AC, 50 Hz ~
15 W/35 VA
8
3-pin XLR
via built-in microphone
:
45° C
a
(steady state):
50° C
C
0.5 m
0.1 m
T 0.5 A, 250 V
5 mm
128
513 x 175 x 225 mm
3.5 kg
No.:
58000641
58000651
58010252
58010256
24/24
00063189.DOC, Version 1.0
