6. TROUBLE SHOOTING

Trouble
No gas flow
Torch flame has
no power
Impossible to ignite
gas
Tip does no heat up
If your device ceases to function correctly, take it to your nearest authorised customer
service centre www.weller-tools.com
7. HOW TO USE THE IRON HOLDER
Always place the soldering tool in the safety rest while not in use!
Put accessory on any box edge as illustrated (one larger nail of holder comes outside of
box and two nails inside).
8. Specifications
Length incl. soldering tip:
Weight incl. gas filling:
Temperature values:
Burning time per gas filling:
Gas consumption per hour
Filling quantity:
Subject to technical alterations and amendments!
See the updated operating instructions at www.weller-tools.com.
Possible reason
Empty gas container
Gas container
probably almost empty
Gas pressure is too
high or too low
Catalyser is damaged
Insufficient gas power
Wrong
175 mm / 6.88"
56.4 g / 1.9 oz.
Soldering iron 250° - 450°C / 482° - 852°F
Hot blow 430°C / 806°F
0.3 hours with gas control lever set at 2.
8g
6 cc / 0.34 cu. inch
English
Correction
Refill
Refill
Adjust
correctly
Position 1-3
Replace
soldering tip
Refill
Correct
