GB | ENGLISH
Technical data
Main dimensions
Controller
Voltage supply
Current consumption
Relay contact:
Form of contact
Switching voltage
Switching current
Switching time
Temperature range
IP rating
Dimensions (W x H x D)
(with fixing plates)
Installation location
Reader
LF Low-frequency magnetic field
Communication type
Temperature range
IP rating
Area of application
Cable length
Dimensions (W x H)
Structure height (T
depth (T )
E
Material
Background lighting
Reading distance
Other
Distance between 2 LF readers
Memory size
Communication between
controller and reader
CE certification
8
60
AC: 8-12 V AC (max. no-load voltage factor 1.3)
DC: Stabilised: 9-12 V DC, unstabilised: max. 20 V DC unloa-
ded
Input protected from inverse-polarity.
max. 150 mA
Opener/closer, potential-free
(can be adjusted using the slide switch behind the clamping
ledge)
max. 30 V AC / max. 40 V DC
max. 2 A AC/DC
1 - 40 sec. (can be adjusted using the potentiometer)
-20 °C to +50 °C (at the installed location)
IP 20
45 mm x 45 mm x 17.5 mm
(55 mm x 45 mm x 17.5 mm)
55 mm with standard switch gear
120 kHz - 140 kHz
Unidirectional
-30 °C to +70 °C
IP 66
Outdoor installation / indoor installation
10 m, cord 4 x 0.14 mm
80 mm x 80 mm
) / installation
11.7 mm / 27.7 mm
A
ASA (weather and UV-resistant)
Duo-LED blue / red
0.2 - 7 cm (depending on the transponder type, configurati-
on, as well as installation location)
min. 0.75 m
100 different transponders
Safe data encryption
Interventions and manipulation ruled out
EN 300 330 / EN 301 489 -1, -3
GEZE SecuLogic GCER 100
