always in the order given below!
Always prevent the black and red clamps
from touching each other or a common
cable!
- Make sure that the vehicle or boat to be
started is switched off (switch or ignition
key in the OFF position).
- Connect the red clamp POS. (+) to the
battery terminal POS. (+), then connect the
black clamp NEG. (-) to the vehicle chassis or
the battery terminal NEG. (-), at a distance
from the fuel pipe.
WARNING: failure to follow these
rules may compromise the
operating life of the device:
- Turn the vehicle ignition to the start
position for no more than 3 seconds.
- If the vehicle or boat does not start, wait
at least 15 seconds before trying again.
- If the vehicle or boat still does not start,
wait at least 2 minutes before trying
again.
After a successful start, with the engine
running, follow the sequence of instructions
below with great care:
- Disconnect the black clamp (negative) from
the vehicle.
- Disconnect the red clamp (positive) from
the vehicle.
- Remove the starter cable connector from
the starter
- Replace the cables and the starter in their
seats inside the case.
It is highly recommended to recharge the
starter as soon as possible.
4.2 Using the starter as a power and/or
charging device:
- Insert the output cable terminal (fig. A-3)
into the appropriate USB port on the starter
(fig. A- );
- Press the ON button seen in figure A-10
once;
- Insert the other cable terminal into the
device to be powered;
4.3 Using the LED lights
- Press and hold the ON button (fig. A-10) for
a few seconds to enable the continuous LED
light function.
The press the button in the following
sequence:
- once to start the blinking light;
- twice to start the emergency signal;
- three times to switch the light OFF.
5. CHARGING
Important! To achieve maximum battery
performance, always charge before use,
then after every time it is used and, in any
case, at least every 3 months.
It is possible to charge the unit using the
relative cable (fig. A-3) connecting the mini
USB terminal to the starter charge socket (fig.
A-5) and the other terminal to a USB output
source (e.g. a computer) or to the 12V car
cigarette lighter socket using the adaptor seen
in figure A-4.
Press the button seen in fig. A-10 once to
check whether the battery needs charging.
The LEDs seen in fig. A-9 indicate the charge
status of the battery, which light up as the
status increases:
- one LED only: low battery;
- all LEDs are on: fully charged battery.
. DISPOSING OF THE BATTERY
When the starter battery is completely
run down it should be sent to a re-cycling
facility. In some countries this is mandatory.
Contact the local special refuse authority for
information on recycling.
WARNING:
Do not burn the battery to dispose of it. This
could cause an explosion. Before disposing of
the battery, apply insulating tape to the bare
terminals to prevent shorting. Do not expose
the battery to intense heat or fire as this could
cause an explosion.
SPECIFICATIONS: DRIVE MINI
Type of battery:
- rechargeable
polymer battery.
Battery capacity:
- 6500 mAh
Starter current (12V):
- 300A
- (1000A peak)
Starter cables:
- polarised terminals.
- copper.
- diameter 5.3mm
- length 240mm
- PVC insulated
Light:
- LED
Input and output sockets:
- one 5V – 2A USB output port
- one (5V – 2A mini USB) input port for
- 5 -
factory-sealed lithium-
(10AWG).
