FastTrak TX2200/2300, TX4200/4300 Quick Start Guide
3. Attach one Serial ATA data cable to each Serial ATA disk drive. Then attach
the other ends of the cables to the connectors on the FastTrak card (below).
FastTrak TX2200/2300 Serial
ATA RAID Controller card
Individual LED
Connectors
FastTrak TX4200 Serial ATA
RAID Controller card
Individual LED
Connectors
Aggregate LED
Connectors
FastTrak
TX2200
Aggregate LED
Connectors
Management
Connector
Port 1 /
Channel 1
Port 2 /
Channel 2
FastTrak
TX4200
6
Port 2 /
Channel 2
Port 1 /
Channel 1
Management
Connector
Port 3 /
Channel 3
Port 4 /
Channel 4
