FastTrak Installation Task List
Step 1: Unpack Your FastTrak Card (below)
Step 2: Install the FastTrak Card (page 4)
Step 3: Install the Disk Drives (page 5)
Step 4: Create Your Logical Disk (page 7)
Step 5: Install Software Drivers (page 14)
This Guide is designed to quickly get your FastTrak TX2200/2300 or 4200/4300
Serial ATA RAID controller card up and running using the default settings, which
will be optimal for most users.
If you wish to modify any of the default settings, please refer to Chapter 3 of the
FastTrak TX2200/2300, TX4200/4300 User Manual on the software CD.
Step 1: Unpack Your FastTrak Card
When you receive the FastTrak Serial ATA RAID card, the package should
contain the items listed below:
• FastTrak TX2200/2300 or TX4200/4300 Serial ATA RAID Controller card
• Quick Start Guide
• 0.65 m (26 inch) Serial ATA data cables. Two 1.5 Gb cables for TX2200, two
3.0 Gb cables for TX2300, four 1.5 Gb cables for TX4200, four 3.0 Gb cables
for TX4300
• Y power splitter cable, one for TX2200/2300, two for TX4200/4300
• CD with all Promise Array Management (PAM) software, Windows drivers,
PAM User Manual and FastTrak TX2200/2300/TX4200/4300 User Manual
If ANY of the contents are missing or appear to be damaged, please contact your
dealer or distributor immediately.
Before installing the adapter into an existing system, backup any
important or useful data. Failure to follow this accepted PC
practice could result in data loss.
Step 1: Unpack Your FastTrak Card
Warning
