2. Remove the inside slot cover of an available 32-bit PCI slot on the
motherboard.Install the FastTrak Serial ATA RAID card into the open PCI
slot. Secure the bracket to the system's frame.
3. Attach your system case's 2- or 4-pin LED cable to the LED connector on the
FastTrak card (see Install the Disk Drives, below).
4. Fasten the controller card bracket to the system case.
Step 3: Install the Disk Drives
The FastTrak TX2200/2300 card supports up to two Serial ATA drives while the
TX4200/4300 card supports up to four. For optimal performance, install Serial
ATA drives of the same model and capacity. The drives' matched performance
allows the logical disk to function better as a single drive.
If you are striping (RAID 0) for performance, use up to four new drives. If
mirroring (RAID 1) for protection, you can use two new drives OR use an existing
drive and a new drive (the new drive must be the same size or larger than the
existing drive).
1. Install the disk drives into the drive bays of your system.
2. Attach the power cables to the disk drives..
If you wish to include your current bootable Serial ATA drive using
the Windows 2000, XP or Server 2003 operating system as part of
a bootable Mirrored (RAID 1) logical disk on your FastTrak card,
do NOT connect the disk drive to the FastTrak yet.
You MUST install the Windows 2000, XP or Server 2003 driver
software first onto this drive while it is still attached to your existing
disk drive controller.
Use of removable disk drive enclosures other than Promise
Technology's SuperSwap is not supported and may result in
performance loss or other undesired results.
Step 3: Install the Disk Drives
Important
Caution
