1550B
MegOhmMeter
Users Manual
PN 3001289
August 2003, Rev. 1, 6/05
© 2003, 2005 Fluke Corporation. All rights reserved.
All product names are trademarks of their respective companies.

Werbung

loading

Verwandte Anleitungen für Fluke 1550B

Inhaltszusammenfassung für Fluke 1550B

  • Seite 1 ® 1550B MegOhmMeter Users Manual PN 3001289 August 2003, Rev. 1, 6/05 © 2003, 2005 Fluke Corporation. All rights reserved. All product names are trademarks of their respective companies.
  • Seite 2 Limited Warranty and Limitation of Liability Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is two years and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This...
  • Seite 3 Table of Contents Title Page Introduction ................1 Contacting Fluke ................ 1 Unpacking the Meter ..............2 Safety Information ..............3 Symbols ..................4 Operating the Meter ..............4 Turning the Meter On and Off ..........4 Using the Pushbuttons............5 Understanding the Display............
  • Seite 4 1550B Users Manual...
  • Seite 5 Pushbuttons ................5 Display Features ..............6 Power Supply Connections ............7 Surface Leakage Current ............8 Guard Terminal Connection ............. 9 Improved Guard Terminal Connection ........9 Connecting to the Circuit Under Test ........10 IR Port on 1550B MegOhmMeter..........18...
  • Seite 6 1550B Users Manual Cover Terminals Safety Shutter Display (LCD) IR Port Pushbuttons Latch Handle asw16F.EPS Fluke 1550B MegOhmMeter...
  • Seite 7 1550B MegOhmMeter Introduction The Fluke 1550B MegOhmMeter (hereafter "the Meter") is a high voltage insulation tester for testing general circuits, including switchgear, motors, and cables. The Meter has the following features: ⇒ Large liquid crystal display (LCD) with text display ⇒...
  • Seite 8 1550B Users Manual Unpacking the Meter The Meter comes with the items shown in Figure 1. If the Meter is damaged or an item is missing, contact the place of purchase immediately. ASW01F.EPS Item Description English Manual AC Power Cord...
  • Seite 9 • Place test leads in proper input terminals. • Do not use the Meter with any parts or cover removed. • Use only Fluke approved replacement parts, and accessories as specified in this manual. • Do not use the Meter if the safety shutter is impaired in any way. The safety shutter (see Frontispiece) prevents access to the test terminals and charger terminals at the same time.
  • Seite 10 1550B Users Manual Symbols Symbols on the Meter and in the manual are explained Table 1. Table 1. Symbols Conforms to European Union standards. TUV GS This product complies with UL3111-1, CAN/CAS C22.2 No.1010.1 for Test and Measurement Equipment Risk of danger.
  • Seite 11 MegOhmMeter Operating the Meter Using the Pushbuttons Use the pushbuttons (Figure 2) to control operation of the Meter, select test results for viewing, and scroll through selected test results. (yes) (no) FUNCTION SCROLL DOWN ENTER TEST ASW02F.EPS Item Button Description Turns the Meter off and on.
  • Seite 12 1550B Users Manual Understanding the Display Display annunciators are shown and described in Figure 3. 5000V 2500V 000V 500V 250V ASW03F.EPS Item Description Interference present. Displayed readings may be outside the specified accuracy range. Electrical breakdown in Ramp mode. Ramp mode indicator.
  • Seite 13 Use a qualified recycler or hazardous materials handler to dispose of dead batteries. Contact your authorized Fluke Service Center for disposal and recycling information. Storing rechargeable lead-acid batteries in a low-charged state could lead to reduced life and/or damage.
  • Seite 14 1550B Users Manual Using the Guard Terminal Note Insulation resistance is measured between the + and − output connections. The Guard terminal (G) is at the same potential as the negative (−) terminal but is not in the measurement path.
  • Seite 15 MegOhmMeter Operating the Meter Figure 6 shows how to prevent surface current leakage by connecting a lead from the Guard terminal to a conductor wrapped around the inner insulation. The surface leakage current is directed to the Guard terminal. This removes the leakage current from the measurement path between the positive and negative terminals, and improves the accuracy of the test readings.
  • Seite 16 Figure 8. Connecting to the Circuit Under Test Note The 1550B is NOT specified below 200 kΩ. This means shorting the leads and performing a test, results in an unspecified but above zero reading. This is normal for this meter’s input circuitry configuration and does not affect readings...
  • Seite 17 MegOhmMeter Making Measurements Options to Consider Before Making an Insulation Test In addition to performing a basic insulation test, the Meter includes a series of features/functions that allow you to more precisely tailor the test to your requirements. These include defining a test voltage, selecting a ramp test, setting a time limit (duration) for the test, measuring polarization index (PI), measuring dielectric absorption ratio (DAR), and measuring capacitance.
  • Seite 18 1550B Users Manual Programming a Test Voltage To set a test voltage in between the pre-set test voltages proceed as follows: button to select TEST VOLTAGE. With the Meter turned on, press the Test Voltage Display 500V ASW05F.EPS Press the button to scroll through the pre-set test voltage options (250 V, 500 V, 1000 V, 2500 V, and 5000 V).
  • Seite 19 MegOhmMeter Making Measurements Selecting a Ramp or Steady-State Test The ramp-test function is an automated test that checks insulation for a breakdown. During a ramp test, the output voltage starts at 0 V and increases linearly (100 V/s) until it reaches the specified test voltage or until a sudden drop in measured resistance is detected.
  • Seite 20 1550B Users Manual Polarization Index (PI) As part of the insulation test, the Meter measures and stores polarization index (PI), when appropriate. Since, by definition, a polarization index test requires 10 minutes to complete, it is measured and stored as invalid data for all insulation tests under 10 minutes.
  • Seite 21 MegOhmMeter Making Measurements To perform an insulation test use the following procedure: With the Meter turned on, set the available measurement options to meet your test requirements. These include: • Test Voltage – Set range: 250V to 5000 V (50 V/100 V steps) •...
  • Seite 22 1550B Users Manual Following termination of an insulation test the Meter beeps when a potentially hazardous voltage remains on the test terminals due to charged-circuit capacitance or from the presence of an external voltage. When the test is terminated, STORE RESULT? is displayed. If appropriate, store the test results as described in the next procedure.
  • Seite 23 MegOhmMeter Viewing Results Stored in Memory Viewing Results Stored in Memory Note INVALID Parameters not appropriate for a test are shown as The Meter can store 99 sets of test data, including: ⇒ Tags ⇒ Ramp on or off ⇒ Insulation Resistance ⇒...
  • Seite 24 You can use FlukeView Forms software to download all of your stored test data to a PC. An infrared adapter is supplied with the Fluke 1550B MegOhmMeter for use in downloading stored test data. Figure 9 shows the location of the IR port on the Meter.
  • Seite 25 Before the USB-IR cable can be used, software drivers must be installed on your Windows PC. See the USB-IR Installation Guide for more information. To connect the 1550B to the PC for use with FlukeView Forms Basic Documenting Software: The 1550B should not be running a test; otherwise, serial communications will be disabled.
  • Seite 26 1550B Users Manual Note Individual test locations cannot be deleted, however, they can be overwritten. Caution The delete function deletes all of your stored test results. Maintaining the Meter Warning To avoid possible electric shock or personal injury, do not attempt to repair or service your Meter beyond what is described in this manual.
  • Seite 27 AC Power Cord (S. Africa) 1552363 Soft Carrying Case 1642656 Infrared Cable Assembly 1578406 Users Manual CD 2099928 English Users Manual 2102980 Quick Reference Card 2099943 Table 3. 1550B Accessories Accessories Part No. Extended Test Lead Set, 25 feet (7.6 meters) 2032761...
  • Seite 28 1550B Users Manual Specifications General Specifications Display 75 mm x 105 mm Power 12 V lead-acid rechargeable battery. Yuasa NP2.8-12 Charger Input (AC) 85 V to 250 V ac 50/60 Hz 20 VA This Class II (double insulated) instrument is supplied with a Class 1 (grounded) power cord.
  • Seite 29 MegOhmMeter Specifications Electrical Specifications The meter’s accuracy is specified for 1 year after calibration at operating temperatures of 0 °C to 35 °C. For operating temperatures outside the range (−20 °C to 0 °C and 35 °C to 50 °C), add ± .25 % per °C, except on the 20 % bands add ±...
  • Seite 30 à appliquer une garantie plus étendue ou différente au nom de Fluke. Le support de garantie est offert uniquement si le produit a été acquis par l’intermédiaire d’un point de vente agréé par Fluke ou bien si l’acheteur a payé le prix international applicable.
  • Seite 31 GARANTÍA LIMITADA Y LIMITACIÓN DE RESPONSABILIDAD (Spanish) Se garantiza que todo producto de Fluke no tendrá defectos en los materiales ni en la mano de obra en condiciones normales de utilización y mantenimiento. El periodo de garantía es de 2 años y comienza en la fecha de despacho. Las piezas de repuesto, reparaciones y servicios son garantizados por 90 días.
  • Seite 32 A Fluke garante que o software funcionará de acordo com as suas especificações técnicas pelo período de 90 dias, e que foi gravado de forma adequada em meio físico sem defeitos. A Fluke não garante que o software esteja livre de defeitos, nem que funcionará...
  • Seite 33 BEPERKTE GARANTIE EN BEPERKING VAN AANSPRAKELIJKHEID (Dutch) Fluke garandeert voor elk van haar producten, dat het bij normaal gebruik en onderhoud vrij is van materiaal- en fabricagefouten. De garantieperiode bedraagt 2 jaar en gaat in op de datum van verzending. De garantie op onderdelen en op de reparatie en het onderhoud van producten geldt 90 dagen.
  • Seite 34 Fluke garanterer ikke at programvaren er feilfri eller fungerer uten avbrudd. Autoriserte Fluke-forhandlere skal bare utvide denne garantien på nye og ubrukte produkter til forbrukere, men har ingen myndighet til å gi en mer omfattende eller forskjellig garanti på...
