position on the wall or window.
•
Do not yet place the cap (A) .
5.2.2
Screw mounting
Make sure that no electricity or similar lines run in
the wall at this location!
For mounting the device using screws, please proceed
as follows:
Position the electronic unit (F) on the desired site
•
on the wall.
•
Mark the holes using the screw holes (D) with a
pen on the wall or on the window.
•
Drill the screw holes with a suitable 5 mm diam-
eter drill bit.
If you are working with a wooden wall, you can
pre-drill 1.5 mm holes to make screws easier to
insert.
•
Fasten the electronic unit by screwing the screws
into the plugs (see figure 4).
Do not yet place the cover (A).
•
5.3
Installation
After installation, you can connect a glass break sensor or
a magnetic contact to the contact interface. To do this,
please proceed as follows:
Start-up
33
