GB
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS FOR COOKER HOOD
MODEL OPERA 230-240 Vac - 50 Hz
Exhausting cooker hood. The equipment is constructed in accordance with European Standards and with the requirements included in
the following Directives: 2006/95EC ( Low Voltage Directive), 2004/108 (Electromagnetic Compatibility).
The equipment (Picture 1 ) is made of the following items :
1) Cooker hood body
2) Telescopic chimney
3) Perimetric glass
Read the instruction manual before installing and/or using the hood.
The unit must not be mounted above cookers fitted with top radiant plate.
Respect all the air discharge regulations.
The air must not be discharged in a pipe used to discharge exhaust fumes produced by gas-fed equipments or fuel-fed equipments (this
does not apply to filtering hoods).
The room must be adequately ventilated when the hoods is used together with other gas-fed or fuel-fed equipments.
For an easy access, it is advisable to move possible furniture under the installation area.
Installation of the hood onto the wall.
The hood is equipped with all the necessary fastenings for its installation, which are suitable for most surfaces. Anyway ask a professional to
verify that the installation surface is strong. Installation must be carried out by qualified installers according to present regulations.
1) Draw and drill the wall as in Picture 2
2) Fix on the wall the screw anchors with the wall cupboard support (A)
3) Fix with screw anchors (C) the support of the telescopic chimney (B)
4) Put the screw anchors on the holes (D)
5) Fix the hood to the wall cupboard support see point 2), two people are needed for this operation
6) Block the equipment with two screws as in (E) , to reach these fastenings open the glass door and remove metallic filters.
7) Place the telescopic chimney on the upper part of the hood and fix the support with screws as in (F).
This equipment must be connected to a grounding plant.
Two types of electrical connection can be used:
1) Using a standard plug to be connected to the power cable and inserted in a mains socket which must be accessible (so that the plug
can be disconnected when servicing is carried out). Make sure that the plug is accessible also after the complete installation of the
equipment.
2) By means of a fixed mains connection, fitting a bipolar switch, which ensures the disconnection, with an opening distance of the
contacts allowing a complete disconnection on the conditions of the overvoltage III category, according to installation regulations.
The ground connection (yellow-green wire) must not be interrupted.
Refer to the plate inside the hood for the mains voltage and frequency ratings.
This cooker hood can be employed as exhausting or filtering.
Exhausting (external evacuation). Kitchen smokes are driven outside through a flue joined to the exhaust pipe flue connector. Install this
flue as indicated in picture 3
This pipe must not under any circumstances be connected to cooker, boiler or burner exhaust pipes, etc.
Filtering (inside recycling). Smokes pass through the activated charcoal filter (Picture 4 - G) to be cleaned and recycled in the kitchen
environment by means of holes from which the purified air will come out. These holes have to be free and communicating with the kitchen
environment.
With the button T4, select the maximum speed of the extraction fan for 5 minutes (button blinking), after which the extraction fan will
automatically switch to the 3rd speed.
PRESENTATION
INSTALLATION

ELECTRICAL CONNECTIONS

EMPLOYMENT

OPERATION
The hood is supplied with a multispeed motor.
The hood should be run at low speed under normal conditions and at higher speeds
only when there is a heavy build-up of fumes or odours.
Ideally, the hood should be switched on as soon as cooking is started and then kept on
until all odours have been eliminated.
The controls consist of touch screen commands. Press TL to turn on the light, press T1 to
swich on the hood at first speed and to switch off the aspirator, press T2-T3-T4 to select
functioning speeds.
