1.
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists.
• Installing and replacing non-original spare parts
• Application other than specified
Note:
Read through the complete text in the operating manu-
al before installing and commissioning the device.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instruc-
tions for the safe, proper and economic operation of
the product, for avoiding danger, for minimising repair
costs and downtimes and for increasing the reliability
and extending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the product in your country.
Keep the operating manual package with the power
tool at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of identical products must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Description of the product
1.
Pressure vessel internal pressure gauge
2.
Safety valve
2a. Exhaust nut
2b. Connection lock
2c. Cap
3.
Handle
3a. Flat head screw
3b. Washer
3c. Hexagonal nut
4.
Seal
5.
Pressure vessel
6.
Lever
7.
Nozzle
7a. Sealing ring
8.
Blasting gun
9.
Blasting hose
9a. Hose clamp
10. Foot
10a. Split pin
11. Blasting material connection
12. Blasting material shut-off valve
13. Wheel axle
14. Wheel
14a. Split pin
14b. Washer
15. Filling nozzle
16. Blasting hose supply line shut-off valve
17. Blasting hose supply line
17a. Blasting material discharge pipe
18. Main supply line shut-off valve
19. Compressed air connection
20. Water separator
20a. Drain valve
3. Scope of delivery
Item
3
3a
3b
3c
13
www.scheppach.com
Quantity
Designation
2
Handle
4x
Flat head screw
8x
Washer (small)
4x
hex nut M6
1x
Wheel axle
GB | 23
