Markings used


catman is a registered trademark of HOTTINGER BALDWIN
MESSTECHNIK GMBH.
All trademarks and brands used in this document are trade names and/or
trademarks belonging to the respective product or the manufacturer/owner.
HOTTINGER BALDWIN MESSTECHNIK GMBH does not lay claim to any
other than their own trade names/trademarks.

1.1 The markings used in this document

Important instructions for your safety are specifically identified. It is essential
to follow these instructions, in order to prevent damage.
Symbol
NOTE
Device -> New
Data rate, 500
Emphasis

1.2 Symbols on the module and their meaning

Symbol:
Meaning: Note supply voltage
This symbol indicates that the supply voltage must lie between 10 and 30 V
HBM
Important
Tip
QuantumX Data Recorder CX22‐W
Significance
This marking draws your attention to a
situation in which failure to comply with
safety requirements can lead to damage to
property.
This marking draws your attention to
information about the product or about
handling the product.
This marking indicates application tips or
other information that is useful to you.
Bold text indicates menu items, as well as
dialog and window titles in the user
interfaces. The arrows between menu items
indicate the sequence in which menus and
sub‐menus are called
Bold text in italics indicates inputs and input
fields in the user interfaces.
Italics are used to emphasize and highlight
texts.
.
DC
A3169-2.0 en/de
