36
If the PC cannot find a server in the network, the search for the server
looks in the "DHCP" settings (Obtain an IP address automatically) and the
"Alternative configuration" (user‐defined address) first of all (the symbol for
the interface in the Windows tray indicates the search, but the symbol may
only appear if the display is configured). It then takes about 20 to 30
seconds to set an automatic address (in DHCP) or the stated alternative
address. During this time, a scan has not found a CX22‐W either.

Could your firewall be responsible for blocking the UDP scan?
Try deactivating your Firewall, or enable TCP port 5001. Also allow UDP
for ports 1200, 1201 and 1300.

Could your antivirus program be responsible for blocking the UDP scan?
Try deactivating your antivirus program, to locate the cause. If the
CX22‐W can then be found, read your antivirus program documentation to
discover how to enable individual programs to access the network (local
subnet). You must enable the same ports as those described under the
firewall.

If a WLAN is also active in your PC, you must test whether the module can
be found when you temporarily switch off the WLAN (just for the search
period). With some WLAN configurations, problems can occur across all
interfaces during a scan.

If your PC has several Ethernet interfaces, try deactivating all the other
Ethernet interfaces.

If the QuantumX Data Recorder Assistant cannot find the CX22‐W, try
setting up a "normal" remote desktop connection.

If you are using the CX22‐W in a sizeable network, contact your network
administrator. There are a series of options in managed networks to limit
or completely prevent data transmission between the individual nodes.
Administrative enabling may also be necessary here.

6.7 Using Ethernet and WLAN in parallel

With the CX22‐W data recorder, you can connect modules via Ethernet and
also connect your PC to the CX22‐W via Ethernet. But you can also connect
the modules via Ethernet, and your PC to the CX22‐W via WLAN. The
following combinations are possible, in addition to connecting the modules via
FireWire:
1. Connect PC to CX22‐W via Ethernet, connect modules via the WLAN hub.
2. Connect PC with CX22‐W via Ethernet, also connect modules via Ethernet
(switch or hub required).
3. Connect PC with CX22‐W via WLAN (Adhoc also possible), connect
modules via Ethernet (switch or hub required).
4. Integrate CX22‐W in the WLAN network, connect PC (and modules) via
the (Ethernet) network.
HBM
QuantumX Data Recorder CX22‐W
A3169-2.0 en/de
