QuantumX Data Recorder CX22‐W
12

System settings, update and recovery

12.1 Changing system settings (Settings)

Important
All changes in the Settings dialog are only permanently saved and active the
next time you switch on, if you click on Commit changes and reboot in the
start screen after making any changes.
The following settings can be changed:

Device name (CX22 name, General tab)
This name is displayed, e.g., in the network.

Password (Remote access password tab)
The password is required for registration (Log On).


Run catman
(catmanAP) at startup, General tab)
Automatically starts catman
See also Chapter 10 on Page 45.

The language version of catman
Select EN for the English interface, DE for the German interface and FR
for the French version of catman
In the start screen (CX22 Start screen), click on Settings and go to the
appropriate tab to change the settings.
Important
Store the password safely after changing it. If you lose it you will need to
restore the system to obtain access to the CX22‐W again.
The Info tab contains information about the CX22 hardware (ID), the device
serial number and the firmware version.

12.2 System restoration (Recovery)

If you have made changes to the system leading to the system becoming
inoperable, you can restore the delivery condition of the system. Neither the
data stored on the removable CF card nor partition D: of the internal memory

with the catman
prepared USB memory stick, a keyboard and, where possible, a (digital)
monitor that you can connect directly to the CX22‐W (DVI output) in order to
A3169-2.0 en/de
AP after switching on the CX22‐W (Launch DAQ software

AP as soon as the system is operational.

AP defaults will be overwritten. You will need a specially
AP (DAQ software language, General tab)

AP.
