SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
H60ME / H60MEY : Demolition Hammer
User Vibration Protection
Low Vibration Handle
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
V
Rated voltage
P
Power Input
n
Full-load speed
Bpm
Full-load impact rate
Weight
kg
(According to EPTA Procedure 01/2014)
Adjustment of the tool position function
Hammering function
Switching ON
Switching OFF
Power lamp
Impact rate selector switch
Display lamp
L
Low impact rate
H
High impact rate
Disconnect mains plug from electrical outlet
Class II tool
SDS max shank
Prohibited action
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed in the below.
○ Plastic case ................................................................. 1
○ Bull Point (SDS-max shank) ........................................ 1
○ Side Handle ................................................................ 1
Standard accessories are subject to change without notice.
APPLICATIONS
Demolishing concrete, chipping off concrete, grooving, bar
cutting, and driving piles.
Application examples:
Installation of piping and wiring, sanitary facility installation,
machinery installation, water supply and drainage work,
interior jobs, harbor facilities and other civil engineering
works.
SPECIFICATIONS
The specifi cations of this machine are listed in the Table on
page 6.
NOTE
Due to HiKOKI's continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action
Inserting SDS-max tools
Removing SDS-max tools
Changing tool direction
Selecting the operating mode
Adujsting the side handle position
Switch operation
Locking-on the On / Off switch
Releasing the On / Off switch
About the power lamp
Speed change
How to use the demolition hammer*
Installing the side handle
Selecting accessories*
*1 Operate this Demolition Hammer by utilizing its empty
weight. The performance will not be better even if it is
pressed or thrust forcibly against the work surface.
Hold this Demolition Hammer with a force just suffi cient
to counteract the reaction.
CAUTION
After long time of use, the housing becomes hot.
Therefore, be careful not to burn your hands.
*2 For detailed information regarding each tool, contact a
HiKOKI authorized service center.
Warming up (Fig. 12)
The grease lubrication system in this unit may require
warming up in cold regions.
Position the end of the bit so makes contact with the
concrete, turn on the switch and perform the warming
up operation. Make sure that a hitting sound is produced
and then use the unit.
10
Figure
2
3
4
5
6
7
8
9
10
11
1
12
14
–
2
Page
2
2
2
3
3
3
3
3
4
4
4
5
7
