22. Install the grease filter and connect the appliance to the mains
of the grease filter is described in chapter 6.1 C
23. Check the correct position of the extractor hood from front and side
perspective (s. fig below). Otherwise, the appliance will not work properly.
WARNING! Operate the appliance with inserted grease filters only.
Otherwise, recirculating-transported fat will deposit in the appliance and
the exhaust system. RISK OF FIRE!

2.6 Electrical connection

Check that the voltage indicated on the rating plate matches the mains voltage of
your home before you connect the extractor hood to the mains.
Check that the extractor hood is installed properly before you connect the
appliance to the mains.
NOTICE! Any damage caused by an appliance that is improperly
connected to the mains is not covered by the warranty or guarantee.
16 If the socket is covered by the chimney, you must plug in the appliance at an earlier point in time.
S (ST 4*8 mm / 2 pcs. in total) to fix the inner chimney
CREWS
RIGHT
I
NNER CHIMNEY BRACKET
I
NNER CHIMNEY
LEANING OF THE GREASE FILTERS
WRONG
~ 72 ~
. The installation
16
.
