TECHNOLOGIE FÜR DEN HAUSHALT
Bedienungsanleitung
Dunstabzugshaube
PKM
6003H
PKM
6004/6004H
PKM
6005
PKM
6088
PKM
6090H
PKM
6091H
Lesen Sie diese Bedienungsanleitung, bevor Sie das Gerät erstmalig in Betrieb nehmen.
Verwahren Sie diese Bedienungsanleitung zur zukünftigen Nutzung an einem sicheren Ort
Please read this manual before you activate the appliance for the first time.
Please retain this manual in a safe place for future reference.
PKM 8888H
PKM 8090H
(
Abbildung ähnlich / Illustration similar )
www.pkm-online.de
TECHNOLOGY FOR DOMESTIC USE
Instruction Manual
Extractor Hood
PKM 9001
PKM 9004
PKM 9090H
PKM 9099
PKM 9999

Werbung

Kapitel

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Pkm PKM 6003H

  • Seite 1 TECHNOLOGIE FÜR DEN HAUSHALT TECHNOLOGY FOR DOMESTIC USE Bedienungsanleitung Instruction Manual Dunstabzugshaube Extractor Hood 6003H PKM 8888H PKM 9001 6004/6004H PKM 8090H PKM 9004 6005 PKM 9090H 6088 PKM 9099 6090H PKM 9999 6091H Abbildung ähnlich / Illustration similar ) Lesen Sie diese Bedienungsanleitung, bevor Sie das Gerät erstmalig in Betrieb nehmen.
  • Seite 2: Inhaltsverzeichnis

    INHALTSVERZEICHNIS KAPITEL THEMA SEITE Vorwort Erklärung der Signalworte Grundlegende Hinweise Hinweise zur Sicherheit und Warnhinweise Aufbau und Anschluss Bedientafel Reinigung und Pflege Problembehandlung Entsorgung Technische Daten Garantiebedingungen Notizen Technische Änderungen bzw. Druckfehler bleiben vorbehalten.. Bitte lesen Sie diese Bedienungsanleitung aufmerksam durch, bevor Sie das Gerät benutzen oder aufbauen.
  • Seite 3: Vorwort

    Produkte nach EN ISO/IEC 17050-1:2004) für folgende PKM Dunstabzugshauben PKM 6003H mit Halogen-Licht; PKM 6004/6004H mit Halogen-Licht; PKM 6005 mit Halogen-Licht; PKM 6088 mit Halogen-Licht; PKM 6090H mit Halogen-Licht; PKM 6091H mit Halogen-Licht; PKM 8888H mit Halogen-Licht; PKM 8090H mit Halogen-Licht;...
  • Seite 4: Erklärung Der Signalworte

    2. ERKLÄRUNG DER SIGNALWÖRTER Beachten Sie unbedingt die in der Bedienungsanleitung eingefügten Signalwörter. Lesen Sie auf dieser Seite nach, welche Bedeutung das entsprechende Signalwort hat. GEFAHR verweist eine Gefahrensituation, ,wenn nicht abgewendet wird, eine unmittelbare Gefährdung für Leben und Gesundheit zur GEFAHR! Folge hat.
  • Seite 5: Grundlegende Hinweise

    3. GRUNDLEGENDE HINWEISE Aufbau Anschluss Ihres neuen Geräts lesen bitte diese Bedienungsanleitung aufmerksam durch. Durch Befolgung darin enthaltenen Anweisungen vermeiden Sie mögliche Bedienungsfehler. Bitte bewahren Sie diese Bedienungsanleitung so auf, dass sie bei Bedarf jederzeit griffbereit ist. Befolgen Sie sorgfältig alle Hinweise, um Unfälle oder eine Beschädigung des Geräts zu vermeiden.
  • Seite 6: Hinweise Zur Sicherheit Und Warnhinweise

    4. HINWEISE ZUR SICHERHEIT UND WARNHINWEISE Transport und Handhabung HINWEIS! Beachten Sie unbedingt die folgenden Sicherheitshinweise, um Beschädigungen an Ihrem Gerät zu vermeiden. 1. Das Gerät muss von mindestens zwei Personen transportiert und angeschlossen werden. 2. Achten Sie darauf, dass sich das Hauptstromkabel nicht hinter dem Gerät befindet oder durch das Bewegen des Geräts beschädigt wird.
  • Seite 7 4. Benutzen Sie kein Verlängerungskabel. Das Gerät darf nach dem Anschluss nicht auf das Stromkabel drücken. 5. Nehmen Sie keine Veränderungen an dem Gerät vor. 6. Wenn das Stromkabel beschädigt ist, darf es ausschließlich vom Hersteller oder einem vom Hersteller autorisierten Kundendienst oder einer gleichartig qualifizierten Person ausgetauscht werden.
  • Seite 8: Maßnahmen Für Einen Sicheren Betrieb

    Maßnahmen für einen sicheren Betrieb 1. Die von dem Gerät angesaugte Luft darf nicht über das Abluftrohr einer Heizung oder anderer, nicht elektrisch betriebener Geräte abgeführt werden. 2. Das Gerät darf ausschließlich mit eingesetzten Fettfiltern betrieben werden, da sich ansonsten durch den Dunst transportiertes Fett in der Haube und/oder im Abluftsystem ablagert.
  • Seite 9: Besondere Maßnahmen Umluftbetrieb

    Besondere Maßnahmen Umluftbetrieb 1. Die angesaugte Luft wird durch einen Kohlefilter ( auch Aktiv-Kohlefilter genannt ) geleitet und im Raum umgewälzt. Der Kohlefilter bindet die durch das Kochen entstehenden Gerüche. 2. Die gefilterte Luft wird durch Luftöffnungen seitlich oder nach oben in den Raum zurück geleitet.
  • Seite 10: Aufbau Und Anschluss

    5. AUFBAU UND ANSCHLUSS Entpacken und Wahl des Standorts WARNUNG! Halten Sie das Verpackungsmaterial ( Polyethylen, Schaumstoffe, etc. ) beim Auspacken fern von Kindern. 1. Packen Sie das Gerät vorsichtig aus. Beachten Sie unbedingt die Hinweise zur Entsorgung des Geräts in dieser Bedienungsanleitung. 2.
  • Seite 11: Allgemeine Angaben Zur Abluftleitung

    3. Der Durchmesser Abluftschlauchs muss Durchmesser Verbindungsrings übereinstimmen. 4. Wenn Sie ein Rückschlagventil benutzen, prüfen Sie, ob dieses nach der Installation des Abluftschlauchs frei öffnen und schließen kann. 5. Je nach Modell kann Ihre Abzugshaube mit einer ( oben ) oder zwei ( oben und hinten ) Abzugsöffnungen ausgestattet sein.
  • Seite 12 Abb. 1 HINWEIS! Der Hersteller ist für Störungen, die durch Nichteinhaltung der in dieser Bedienungsleitung aufgeführten Anweisungen und Hinweise entstehen, nicht verantwortlich.
  • Seite 13 Gerätekomponenten Abb. 2 Haube Basisschacht Teleskopschacht Montageleiste Flacheisen Kochfeld...
  • Seite 14 Luftstrom Abluft Luftstrom Umluft über Kamin...
  • Seite 15: Einbaumaße

    Einbaumaße PKM 6003H PKM 6004 / 6004H...
  • Seite 16 PKM 6005 PKM 6088 PKM 6090H...
  • Seite 17 PKM 6091H PKM 8888H...
  • Seite 18 PKM 8090H...
  • Seite 19 PKM 9001 PKM 9004...
  • Seite 20 PKM 9090H PKM 9099...
  • Seite 21: Montage Der Haube

    PKM 9999 Montage der Haube 1. Halten Sie immer den notwendigen Sicherheitsabstand zwischen Haube und Kochstelle ein. 2. Reinigen Sie vor dem Aufbau des Geräts unbedingt dessen nähere Umgebung, damit später kein Staub oder Schutt eingesaugt wird. 3. Der Abluftschlauch darf nicht zusammen mit Gasrohren, Heißluftrohren usw. in dem selben Schacht verlaufen.
  • Seite 22 Abb. 2 Bei Bedarf kann ein Abluftschlauch mit. Adapter mit Rückschlagventil ( nur bei bestimmten Modellen im Lieferumfang enthalten) am Gerät angebracht werden. Hierzu wird der Adapter mit 4 Schrauben über der Öffnung auf der Oberseite des Geräts montiert. Anschließend kann der Abluftschlauch auf den Adapter gesteckt werden.
  • Seite 23 A Ableitung Abluftschacht B Seitliche Ableitung durch Wand Abb. 3 1. Halten Sie die Aufhängevorrichtung für die Haube an die Wand. Achten Sie hierbei darauf, eine Position zu wählen, die den Abmessungen des Abluftkamins entspricht. 2. Markieren Sie die Bohrungen mit einem Bleistift. 3.
  • Seite 24: Montage Des Abluftschlauchs Bei Modellen Mit Vormontierter Austrittsweiche

    Bitte überprüfen Sie, ob Ihr Gerät aus der Front-und Seitenperspektive gerade und waagerecht an der Wand angebracht ist, da das Gerät ansonsten nicht ordnungsgemäß arbeitet. Montage des Abluftschlauchs bei Modellen mit vormontierter Austrittsweiche Die Aufnahme für den Abluftschlauch ist vormontiert. Bei Betrieb mit Abluft müssen die beigelegten Schutzklappen ( Halbmonde )eingesetzt werden.
  • Seite 25: Elektrischer Anschluss

    Je nach Modell kann der untere Kamin mit Schrauben befestigt werden. Elektrischer Anschluss  Betreiben Sie das Gerät nur mit 220V ~ 240V / 50Hz Wechselstrom. Verwenden Sie ausschließlich eine dafür geeignete Steckdose, die sich nahe an Ihrem Gerät befinden muss. ...
  • Seite 26: Wechsel Bei Modellen Mit Acrylfiltern

    Wechsel bei Modellen mit Acrylfiltern Kohlefilter 1. Schalten Sie das Gerät vor der Montage von Kohlefiltern unbedingt aus und trennen Sie es von der Stromversorgung. 2. Entfernen Sie die Fettfilter. 3. Die Kohlefilter werden auf beiden Seiten auf den Motor der Haube gesteckt (A). und durch eine Drehbewegung befestigt (B).
  • Seite 27: Geräte Mit Kohlefilter Cf

    Geräte mit Kohlefilter CF 120  Der Kohlefilter CF 120 ist rechteckig. Zur Montage legen Sie den Kohlefilter bitte in die dafür vorgesehenen Aufnahmestellen seitlich am Motor ein. (Aktiv)Kohlefilter Bestellen Sie Verbrauchsteile wie Kohlefilter bei (Tel. 02841/178738, Fax 21950) 6. Bedientafel Hinweis zu allen Bedientafeln ...
  • Seite 28 HINWEIS! Drücken Sie nie mehrere Leistungsstärkentasten gleichzeitig. Drücken Sie nie eine weitere Leistungsstärkentaste, wenn das Gerät bereits auf einer eingestellten Stufe arbeitet.  Niedrigste Einstellung  Einmal drücken = Funktion an  Nochmaliges Drücken = Funktion aus  Mittlere Einstellung ...
  • Seite 29 AYD 008  Schaltet den Motor ab.  Niedrigste Einstellung  Mittlere Einstellung  Höchste Einstellung  Licht ein/aus AYD 009  Erstes Berühren startet die Haube. Das Gerät läuft nun auf der niedrigsten Stufe.  Zweites Berühren stellt die mittlere Betriebsstärke ein. ...
  • Seite 30: Einstellen Der Uhrzeit

     Jedes Berühren verringert die Betriebsstärke um den Faktor 1.  Läuft das Gerät auf der niedrigsten Stufe, schaltet ein weiteres Berühren das Gerät aus.  Berühren schaltet das Licht ein oder aus  Sie können das Licht auch einschalten, wenn das Gerät nicht in Betrieb ist.
  • Seite 31 AYD 011 / AYD 013 / AYD 018...
  • Seite 32  Schaltet das Gerät ein oder aus.  einmaliges Drücken: niedrigste Leistungsstufe.  zweimaliges Drücken: mittlere Leistungsstufe.  dreimaliges Drücken: höchste Leistungsstufe.  ein viertes Drücken setzt das Gerät wieder auf die niedrigste Leistungsstufe zurück.  Schaltet das Licht ein oder aus. ...
  • Seite 33 AYD 015 / AYD 016 1 Licht 0: Licht aus 1: Licht an 2 Leistungsstufen 0: Aus 1: niedrigste Einstellung 2: mittlere Einstellung 3: höchste Einstellung AYD – 020 Einschalten: das Gerät befindet sich im Bereitschafts- Modus, sobald Sie es an die Stromversorgung angeschlossen haben.
  • Seite 34  Jedes Berühren verringert die Betriebsstärke um den Faktor 1.  Läuft das Gerät auf der niedrigsten Stufe, schaltet ein weiteres Berühren das Gerät aus.  Berühren schaltet das Licht ein oder aus.  Wenn der Motor oder das Licht noch an ist: berühren Sie die Timer Taste und das Gerät läuft 10 Minuten, um sich dann automatisch abzuschalten.
  • Seite 35 AYD 035 Einschalten: das Gerät befindet sich im Bereitschafts- Modus, sobald Sie es an die Stromversorgung angeschlossen haben. Timer  Wenn der Motor oder das Licht noch an ist: berühren Sie die Timer Taste und das Gerät läuft 5 Minuten, um sich dann automatisch abzuschalten. Leistungsstärke ...
  • Seite 36: Reinigung Und Pflege

    7. REINIGUNG UND PFLEGE WARNUNG! Trennen Sie das Gerät vor allen Wartungs- und Reinigungsarbeiten von der Stromversorgung. Reinigung Gerät 1. Verwenden farbig lackierten Geräten niemals alkoholhaltige Reinigungsmittel, weil diese Verfärbungen verursachen. 2. Die Fettfilter müssen regelmäßig gereinigt oder ersetzt werden. Mit Fett gesättigte Filter fangen leicht Feuer und verbreiten unangenehme Gerüche.
  • Seite 37: Ersetzen Der Fettfilter

    5. Beschädigen Sie beim Reinigen von Metallfiltern nicht das Gitter. Durch häufiges Reinigen und die Verwendung von aggressiven Reinigungsmitteln können Farbveränderungen der Metalloberfläche entstehen. 6. Solche Veränderungen haben keinen Einfluss auf die Leistung der Filter und sind kein Reklamationsgrund. WARNUNG! Eine Nichtbeachtung der Reinigungs- und Pflegeanleitungen führt zu einem erhöhten Brandrisiko aufgrund von Fettablagerungen.
  • Seite 38: Austausch Des Leuchtmittels - Halogen

    Austausch des Leuchtmittels - Halogen Berühren Sie das neue Leuchtmittel nicht mit bloßen Händen. Der Fingerschweiß reduziert dir Haltbarkeit des Leuchtmittels. Verwenden Sie ein dünnes Tuch oder dünne Stoffhandschuhe. 1. Trennen Sie das Gerät von der Stromversorgung. 2. Lassen Sie das Leuchtmittel abkühlen, bevor Sie es austauschen. 3.
  • Seite 39: Problembehandlung

    8. PROBLEMBEHANDLUNG FEHLER MÖGLICHE URSACHE MASSNAHMEN  Gerät arbeitet  Das Gerät  Überprüfen überhaupt nicht. Stromstecker nicht fragliche Steckdose, Steckdose angeschlossen. indem Sie ein anderes  Der Stromstecker ist locker. Gerät ebenda  Die Steckdose wird nicht mit anschließen. Strom versorgt.
  • Seite 40: Entsorgung

     falls an der Abdeckplatte des Mauerkasten feste und sehr schräg stehende Lamellen sind, kann dadurch der Luftstrom beeinträchtigt werden. Entfernen Sie zum Überprüfen die Abdeckplatte.  Bringen Sie eine Abdeckplatte mit beweglichen Lamellen an, die den Luftstrom am wenigsten hemmen. ...
  • Seite 41 WARNUNG! Achten Sie beim Entpacken unbedingt darauf, dass die Bestandteile der Verpackung ( Polyäthylentüten, Polystyrenstücke ) nicht in die Reichweite von Kindern gelangen. → → Materialien, die mit dem Symbol gekennzeichnet sind, sind wiederverwertbar.  >PE< = Polyethylen  >PS< = Styropor ...
  • Seite 42: Technische Daten

     Nähere Informationen erhalten Sie von Ihrem Händler oder bei Ihrer entsprechenden städtischen Einrichtung. 10. TECHNISCHE DATEN Für alle Datenblätter Ob Ihr Gerät mit Kohlefiltern ausgestattet ist, hängt von dem von Ihnen gekauften Modell ab. PKM 6003 Edelstahl 520m - 2*50 Kamin - Halogen BLATT 1 Geräteart...
  • Seite 43 57,00 66,00 40,00 Gewicht netto / brutto in kg 13,50 15,50 Prüfzeichen CE / GS PKM 6004 H Edelstahl 520m - 2*40 Kamin - Halogen Änderungen zu Datenblatt 1 BLATT 1a Teleskopkamin ausziehbar von bis 40-78 cm- Gesamthöhe durch Teleskopkamin...
  • Seite 44 Abmessungen Verpackung H/B/T in cm 66,00 46,00 57,00 Gewicht netto / brutto in kg 16,00 18,00 Prüfzeichen CE / GS PKM 6088 Edelstahl 520m - 2*50 Kamin - Halogen BLATT 3 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft...
  • Seite 45 Abmessungen Verpackung H/B/T in cm 57,00 66,00 48,00 Gewicht netto / brutto in kg 17,00 21,00 Prüfzeichen CE / GS PKM 6090 H Edelstahl 520m - 2*40 Kamin - Halogen BLATT 4 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft...
  • Seite 46 Gewicht netto / brutto in kg 10,00 12,00 Prüfzeichen CE / GS PKM 6091 H Edelstahl 350m - 2*40 Kamin - Halogen BLATT 5 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft 520 m Einbaubreite 60/90 cm Wandmontage / Unterbau / Deckenmontage...
  • Seite 47 PKM 8888 H Edelstahl 350m - 2*40 Kamin - Halogen BLATT 6 Geräteart Dunstabzugshaube Material Edelstahl, Glasschirm Maximale Luftumwälzung in Betrieb Abluft 350 m Einbaubreite 60 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 40-78 cm Gesamthöhe durch Teleskopkamin...
  • Seite 48 PKM 8090 H Edelstahl 500m - 2*40 Kamin - Halogen BLATT 7 Geräteart Dunstabzugshaube Material Edelstahl, Glasschirm Maximale Luftumwälzung in Betrieb Abluft 500 m Einbaubreite 60 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 40-78 cm Gesamthöhe durch Teleskopkamin...
  • Seite 49 PKM 9001 Edelstahl 700m - 2*50 Kamin - Halogen BLATT 8 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft 700 m Einbaubreite 90 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 50-98 cm Gesamthöhe durch Teleskopkamin...
  • Seite 50 PKM 9004 Edelstahl 520m - 2*40 Kamin - Halogen BLATT 9 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft 700 m Einbaubreite 90 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 40-78 cm Gesamthöhe durch Teleskopkamin...
  • Seite 51 PKM 9090 H Edelstahl 520m - 2*40 Kamin - Halogen BLATT 10 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft 520 m Einbaubreite 90 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 40-78 cm Gesamthöhe durch Teleskopkamin...
  • Seite 52 PKM 9999 Edelstahl 520m - 2*50 Kamin - Halogen BLATT 11 Geräteart Dunstabzugshaube Material Edelstahl Maximale Luftumwälzung in Betrieb Abluft 520 m Einbaubreite 60 cm Wandmontage / Unterbau / Deckenmontage Drucktasten AYD 008 Teleskopkamin ausziehbar von bis 50-98 cm Gesamthöhe durch Teleskopkamin...
  • Seite 53: Garantiebedingungen

    Garantiezeit auf Wunsch das alte Gerät kostenfrei durch ein neues Gerät gleicher Art, gleicher Güte und gleichen Typs ersetzt. Sofern das betroffene Gerät zum Zeitpunkt der Fehleranzeige nicht mehr hergestellt wird, ist PKM berechtigt, ein ähnliches Gerät zu liefern. Der Geräteaustausch erfolgt grundsätzlich in dem Geschäft, in dem der erste Verbraucher das Gerät gekauft hat;...
  • Seite 54 5. Schäden am Produkt, die durch nicht fachgerechte Installation oder Transport verursacht wurden; 6. Schäden infolge nicht haushaltsüblicher Nutzung; 7. Schäden, die außerhalb des Gerätes durch ein PKM-Produkt entstanden sind - soweit eine Haftung nicht zwingend gesetzlich angeordnet ist. Die Gültigkeit der Garantie endet bei 1.
  • Seite 55 INDEX CHAPTER SUBJECT PAGE Preface Explanation of the warning notice Basic advice Safety instructions and warnings Installation Control panel Cleaning and maintenance Trouble shooting Waste management Technical data Guarantee conditions Notes Technical modifications as well as misprints shall remain reserved. Please read this manual carefully before you use or install the appliance.
  • Seite 56: Preface

    (according to EN ISO/IEC 17050-1:2004) for the products: PKM Extractor Hoods PKM 6003H with halogen-light; PKM 6004/6004H with halogen-light; PKM 6005 with halogen-light; PKM 6088 with halogen-light; PKM 6090H with halogen-light; PKM 6091H with halogen-light; PKM 8888H with halogen-light; PKM 80908H with halogen- light;...
  • Seite 57: Explanation Of The Warning Notice

    2. EXPLANATION OF THE WARNING NOTICE Strictly observe the below mentioned warning notice. Please note the meaning of each warning notice. DANGER indicates a hazardous situation which, if ignored, will result in death or serious injury. DANGER! WARNING indicates a hazardous situation which, if ignored, could result in death or serious injury.
  • Seite 58: Basic Advice

    3. BASIC ADCIVE Dear client Please read this manual carefully before using the appliance for the first time. You will avoid malfunctions by thoroughly following the advice. Please store this instruction manual in a safe place so you can use it whenever it is needed. The instructions and descriptions this manual contains are designed for various types of cooker hoods.
  • Seite 59: Safety Instructions And Warnings

    4. SAFETY INSTRUCTIONS AND WARNINGS NOTICE! Strictly observe the following safety instructions to avoid any damage to your appliance. Transport and handling 1. The appliance must be transported by at least two persons. 2. The supply cord must not be caught behind the appliance while or after moving it. 3.
  • Seite 60: Fire Prevention

    7. Do not attempt to repair the appliance alone. Repairs carried out by unauthorized persons can cause serious damage. Contact the shop you purchased the appliance at and use original spare parts only. Fire prevention 1. If gas is set free in your home: ...
  • Seite 61 Special measures extraction mode 1. The extracted air is conducted by an exhaust hose. You need an exhaust duct or an exhaust pipe, which conduct the extracted air outside your home. 2. Whenever the hood is run in company with chimney-conducted firing ( e.g. coal furnace ), ensure there is sufficient air supply to the room where the appliance is installed.
  • Seite 62: Installation

    5. INSTALLATION Unpacking and positioning WARNING! While unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be kept away from children. 1. Unpack the appliance carefully. Dispose of the packaging as described in the chapter waste management. 2. Completely remove the transport-protection. Be very careful and do not use any aggressive or abrasive detergents to remove residuals of the transport-protection.
  • Seite 63 6. The extractor hood is normally preset for the use of the top outlet as well as for extraction mode. 7. The idle outlet is covered by a plastic cap. You can remove this cap by turning it anticlockwise. Use the cap to cover the idle outlet. 8.
  • Seite 64 NOTICE! The manufacturer is not liable for any damage or malfunction which may occur in consequence of disregarding the instructions and information in this manual. Extractor hoods components hood Base chimney Telescopic chimney Mounting rail Flat bar All instructions concerning air conduction are not valid for the use of the recirculating mode.
  • Seite 65 Airflow extractor mode Airflow recirculating mode via chimney...
  • Seite 66 Fitting dimensions PKM 6004 / 6004 H PKM 6005...
  • Seite 67 PKM 6088 PKM 6090 H...
  • Seite 68 PKM 6091 H PKM 8090 H...
  • Seite 69 PKM 8888 H PKM 9001...
  • Seite 70 PKM 9004 PKM 9090 H...
  • Seite 71 PKM 9099 PKM 9999...
  • Seite 72 Installation of the hood 1. Strictly observe the minimum distance between hood and hob. 2. Clean the surrounding of the installation area before you install the appliance so the appliance will not extract any dust or construction waste. 3. The exhaust hose must not run in the same air duct as gas tubes, hot air tubes et cetera.
  • Seite 73 You can fix an exhaust hose with an adapter ( depending on model if included in delivery ) on the appliance. Fix the adapter with four screws above the opening on the top of the appliance and insert the exhaust hose. The exhaust hose must horizontally lead away from the appliance respectively must not been bent more than 120 .
  • Seite 74 Installation of the hood wall 1. Position the suspension device on the wall. Choose a proper position which meets the dimensions of the chimney. 2. Mark the position of the holes with a pencil. 3. Now drill the holes and fix the suspension device with the screws and dowels/plugs.
  • Seite 75 Fixing of the exhaust hose Models with preassembled air outlet Preassembled air outlet for fixing the exhaust hose. You must install the crescent-shaped protective covers, when you run the appliance in extraction mode. The covers protect the motor from the outdoor air and draught. View of segment of an exhaust hose...
  • Seite 76: Electrical Connection

    Depending on model the lower chimney can be fixed with screws. Electrical connection  An electrical supply of 220-240V AC / 50 Hz is required. Only use a suitable and properly grounded socket near the appliance.  For your personal safety, the appliance must be grounded. The appliance is equipped with a 3-phase grounding plug.
  • Seite 77 Changing the filters Models with acrylic filters...
  • Seite 78: Carbon Filter

    Carbon filter 1. Before you install any carbon filters: switch the appliance off and disconnect it from the mains. 2. Remove the grease filters. 3. Insert the carbon filters on both sides of the motor (A) and fix them (B). 4.
  • Seite 79: Control Panel

    6. CONTROL PANEL General Information  The functions represent a specific capacity of your appliance.  The corresponding values are described in chapter 10, data sheets.  The corresponding code numbers of the panels are described in chapter 10, data sheets.
  • Seite 80 NOTICE! Never press more than one key at the same time. Never press another key 1-3 while the appliance is running.  Lowest setting  Press = function on  Press again = function off  Medium setting  Press = function on ...
  • Seite 81  witches the motor off.  Lowest setting.  Medium setting.  Highest setting.  Light on/off AYD 009  First touch starts the appliance. The appliance runs in the lowest setting.  Second touch: the appliance runs in the medium setting.
  • Seite 82: Setting The Time Of Day

    Setting the time of day 1. Press and hold the timer sensor, until the first two digits of the display start to flash. 2. Release the timer sensor, then use the Add/ON sensor and Dec/OFF sensor to set the hour time. 3.
  • Seite 83  Switches the appliance on/off.  Press once: lowest setting.  Press twice: medium setting.  Press 3 times: highest setting.  Press 4 times: reset to lowest setting.  Switches the light on/off.  Activates the timer function.. When you next switch the hood on, it will remember the speed it was running at when it was last used.
  • Seite 84 7. If “59” appears on the LED display, the speed selection will no longer operate and if “00” appears on the LED display, the light ON/OFF button will no longer operate. 8. When the correct minute digits appear on the LED display, press the timer button a third time to confirm the time of day.
  • Seite 85 1 Light 0: light off 1: light on 2 Speed 0: off 1: lowest setting 2: medium setting 3: highest setting AYD – 020 Power on: Connect the power, and then the machine enters standby status.  First touch starts the appliance. The appliance runs in the lowest setting.
  • Seite 86 AYD 035 Power on: Connect the power, and then the machine enters standby status. Timer  When the motor or light is still on, press the Timer key, and the hood will run 10 minutes , then stop and enter standby status .
  • Seite 87: Cleaning And Maintenance

    7. CLEANING AND MAINTENANCE WARNING! Disconnect the appliance from the mains before you clean or maintain it. Cleaning appliance 1. Never use any alcohol-containing detergents to clean matt black painted appliances as these detergents cause changes in colour. 2. Clean or replace the grease filters regularly. Fat-saturated filters will easily catch fire and cause unpleasant odours.
  • Seite 88 WARNING! Disregarding the cleaning and maintenance instructions will cause an increased risk of fire. Changing the grease filter You must replace the grease filters periodically. Follow the instructions given below. Type of filter Replacement Acrylic grease filter Once or twice a month depending on frequency of use Metal You do not need to replace metal filters.
  • Seite 89: Trouble Shooting

    Replacing of the power cord DANGER! The power cord must be replaced by a qualified and authorized professional only. 8. TROUBLE SHOOTING MALFUNKTION POSSIBLE CAUSE MEASURE  The appliance  The plug of the appliance is not  Check the does not work at connected to the socket.
  • Seite 90: Waste Management

     the diameter of the air duct from hood to wall-box inclusive should be 120-150 mm otherwise the capacity of the motor may be decreased.  if you have installed a fly screen on the wall-box, the air vent may be obstructed. Check by removing the fly screen.
  • Seite 91 WARNING! During unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be kept away from children. Materials with this symbol on are recyclable.  >PE< = Polyethylene  >PS< = Styrofoam  >PP< = Polypropylene These materials can be recycled when you depose them of in a suitable collecting container of your local facilities.
  • Seite 92: Technical Data

    10. TECHNICAL DATA Nota bene : all data sheets Whether your appliance is equipped with carbon filters or not depends on the model you purchased. PKM 6004 Stainless steel 520m - 2*50 Chimney - Halogen DATA SHEET 1 Model...
  • Seite 93 PKM 6004 H Stainless steel 520m - 2*40 Chimney - Halogen Modification of DATA SHEET 1 DATA SHEET 1a Telescopic chimney from - to 40-78 cm- Total height with telescopic chimney 86,00 cm Light amount / Watt / type 2*28 Watt...
  • Seite 94 PKM 6088 Stainless steel 520m - 2*50 Chimney - Halogen DATA SHEET 3 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 520 m Width 60 cm Installation wall / substructure / ceiling Electronic keys AYD 001...
  • Seite 95 PKM 6090 H Stainless steel 520m - 2*40 Chimney - Halogen DATA SHEET 4 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 520 m Width 60 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 96 PKM 6091 H Stainless steel 350m - 2*40 Chimney - Halogen DATA SHEET 5 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 520 m Width 60/90 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 97 PKM 8888 H Stainless steel 350m - 2*40 Chimney - Halogen DATA SHEET 6 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 350 m Width 60 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 98 PKM 8090 H Stainless steel 500m - 2*40 Chimney - Halogen DATA SHEET 7 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 500 m Width 60 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 99 PKM 9001 Stainless steel 700m - 2*50 Chimney - Halogen DATA SHEET 8 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 700 m Width 90 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 100 PKM 9004 Stainless steel 520m - 2*40 Chimney - Halogen DATA SHEET 9 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 700 m Width 90 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 101 PKM 9090 H Stainless steel 520m - 2*40 Chimney - Halogen DATA SHEET 10 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 520 m Width 90 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 102 PKM 9999 Stainless steel 520m - 2*50 Chimney - Halogen DATA SHEET 11 Model Extractor hood Material Stainless steel Maximum extracting capacity / extractor mode 520 m Width 60 cm Installation wall / substructure / ceiling Push buttons AYD 008...
  • Seite 103: Guarantee Conditions

    Replaced components or exchanged appliances demise to us as our property. The guarantee claim does not cover: 1. fragile components as plastic, glass or bulbs; 2. minor modifications of the PKM-products concerning their authorized condition if they...
  • Seite 104: Notizen

    5. damage caused by non-professional installation and haulage; 6. damage caused by non common household use; 7. damages which have been caused outside the appliance by a PKM-product unless a liability is forced by legal regulations. The validity of the guarantee will be terminated if: 1.
  • Seite 105 TECHNOLOGIE FÜR DEN HAUSHALT TECHNOLOGY FOR DOMESTIC USE www.pkm-online.de Stand:28.01.2013 Updated: 01/28/2013...
