Technical specs

Power supply and consumption
Type of power supply
ES
Stand-by consumption
Maximum consumption
EN
Connection and communications
Type of cable
FR
Communication wires
Power supply wires
Maximum distance
IT
PT
DE

WIRELESS THINK THERMOSTAT (AZCE6THINKR)

Graphic interface with low-energy e-ink screen and capacitive buttons for controlling zones
in Airzone systems. Wireless communications. Powered by battery button CR2450. Finished
in steel and glass. Available in white or black.
Functionalities:
•
Available in Spanish, English, French, Italian, German and Portuguese.
•
Control of temperature, operating mode (Master thermostat) and system speed
(Master thermostat and in fancoil installations).
•
Room temperature and relative humidity reading.
•
Sleep function.
Technical specs
Power supply and consumption
Type of power supply
Useful life of battery
Stand-by consumption
Maximum consumption
Connection and communications
Communication frequency
Maximum power
Maximum distance in open space
30
Vdc
12 V
V max
145 mA
I max
0,876 W
1,74 W
Shielded twisted pair
2 x 0,22 mm 2
2 x 0,5 mm 2
40 m
Vdc
V max 3,3 V
30 mA
I max
CR2450
Battery
2 years
0,01 mW
100 mW
868 MHz
0 dBm
40 m
Operating temperatures
Storage
Operation
Set-point temperature range
Reading accuracy
Display accuracy
Relative humidity
Mechanical aspects
Assembly Surface through support
Protection class IP 20
Type of probe Airzone_NTC_10K
Weight 198 g
Dimensions (WxHxD) 92x 92x15,85 mm
Operating temperatures
Storage
Operation
Set-point temperature range
Reading accuracy
Display accuracy
Relative humidity
Mechanical aspects
Assembly Surface through support
Protection class IP 20
Type of probe Airzone_NTC_10K
Weight 180 g
Dimensions (WxHxD) 92x 92x15,85 mm
-
±0,1 ºC
±0,1 ºC
±4 %
-
±0,1 ºC
±0,1 ºC
±4 %
