EUROLITE IR-15 remote control
Danger of explosion when battery is replaced improperly. Only replace by the same type.
Please dispose of old and used batteries properly. Batteries are hazardous waste and should
No.
Key (Step 1)
1
BLACKOUT
2
AUTO
3
SOUND
4
FLASH
5
SPEED
Please note: The DMX key has no function.
1
When actuating a button, always hold the remote control
in the direction of the sensor. There must be visual connection between
the remote control and the sensor.
2
The remote control is supplied with a battery inserted.
An insulating foil between the battery and the battery contacts prevents
the battery from being discharged during storage. Prior to the first
operation remove the foil from the battery support on the rear side of the
remote control. Otherwise operation of the remote control is not possible.
3
If the range of the remote
control decreases (10 meters as a maximum),
replace the battery. For this purpose, on the
rear side of the remote control press the small
bar with the groove to the right and at the same time remove the battery
support. For operation, one 3 V button cell type CR 2025 is required.
When inserting, pay attention that the positive pole of the button cell
shows upwards in the support.
CAUTION!
not be disposed of with regular domestic waste!
Step 2
Description
Blackout
Internal program
Sound controlled internal program
Strobe effect - available for AUTO / SOUND programs
+/-
Select the desired speed for AUTO / SOUND programs
20/22
00100793, Version 1.0
