DESCRIPTION OF THE DEVICE

Features

Classic LED beam effect with IR control
Bright R, G, B and W LEDs are arranged behind each of the 5 lenses
•
When using smoke, the brilliant colors are especially rich
•
Internal program
•
Constantly changing color patterns
•
Flicker-free projection
•
Modifiable program speed
•
Sound-controlled via built-in microphone
•
Microphone-sensitivity adjustable via rotary-control
•
Sound-control or auto mode available
•
Strobe effect
•
Additional control via included EUROLITE IR-15 remote
•
Easy hanging installation
•
Locking possibility at the mounting bracket
•
Ready for connection via included IEC power cord with safety power plug
•
Switch-mode power supply for operation between 100 and 240 volts
•

Overview

Front
1
2
1. Mounting bracket/holes for mounting clamp
3
2. IR sensor
3. Lenses
16/22 00100793, Version 1.0
