Cleaning wall surfaces

Fasten the T-Racer directly to the high-pressure gun.
1 Press the bayonet connection of the T-Racer into
the connection of the high-pressure gun, then turn
by 90° until it locks into place.
2 Tighten the union nut.
 Adjust the twist grip "Power" in accordance with the
surface to be cleaned.
CAUTION
Always hold the T-Racer at the handle while cleaning
the walls.
 Illustration

Control elements

"Power" turning handle
The turning handle "power" is used to change the dis-
tance of the high-pressure nozzles to the surface to be
cleaned.
 Illustration
Sturdy surfaces (e.g. tiles, concrete, stone)
 Set turning handle "power" to "HARD".
For the effective cleaning of hard-to-remove con-
tamination.
Sensitive surfaces (e.g. wood)
 Set turning handle "power" to "SOFT".
For the gentle cleaning of sensitive surfaces.
Foot pedal for surface cleaning
 Illustration
For normal surface cleaning, operate the foot
switch for surface cleaning (a).
A water stream will be emitted from the two high-
pressure nozzles in the rotor arm.
Foot pedal for edge cleaning
 Illustration
For edge and corner cleaning, operate the foot
switch for edge cleaning (b).
A water stream will be emitted from green high-
pressure nozzle.
Note
For edge and corner cleaning no detergent is added.
In order to achieve the optimum cleaning result, guide
the T-Racer along the corners.
Dosage regulator for detergent
 Illustration
The detergent supply is adjusted by means of the
dosing regulator for detergent.
You can use the extension pipe with any Kärcher acces-
sory.
Use a moist cloth and clean the appliance after use.
Store the appliance in a frost free area.
The device can be suspended into the KÄRCHER or-
ganiser for storage.
10
Tip
Care
Troubleshooting
Pressure washer does not build up pressure or is
pulsating.
 Dismantle the high-pressure nozzles, check the
high-pressure nozzles for damage, rinse the T-
Racer with clean water then reinstall the high-pres-
sure nozzles.
You need to use the matching high pressure noz-
zles to ensure that your high pressure cleaner
works properly.
 Select and install the high-pressure nozzles in ac-
cordance with the pressure washer used.
No detergent infeed
 Check the settings at the dosage regulator for de-
tergent.
 Check whether the Plug 'n' Clean detergent bottle
is placed into the detergent connection facing
down.
