hanseatic HKGK17955CNFI Gebrauchsanleitung Seite 69

3. Position the appliance upright.
4. Attach the freezer door (6).
(28)
(29)
(30)
5. Use the screws (28) to attach the middle
hinge (29).
If necessary, use the two washers (30) to
adjust the gaps between the hinge and
the doors.
6. Then reattach the fridge door (2).
(27)
(26)
7. Attach the upper hinge (27) and fasten it
using the screws (26) provided.
(23)
(42)
8. Fit the left hinge cover (42) and fasten it
using a screw (23).
9. Use the other screw (23) to fasten the
cover (25).
(23)
(25)
Start-up Page EN-31
