Page EN-30 Start-up
2. Use the size 10 spanner and a pair of
pliers to loosen the nut (36) of the hinge
bolt (35) on the lower hinge (32), and
then remove it together with the retaining
ring (37).
(35)
(32)
3. Flip over the hinge (32) and screw the
hinge bolt (35) back in.
Preparing the doors
(38)
1. Keep the included plastic inserts (38) for
the fridge door and (39) for the freezer
door ready to hand.
(40)
2. Loosen the screw on the plastic insert (40)
for the fridge door and remove the plastic
insert.
3. Screw down the plastic insert (38) on the
opposite side of the fridge door.
(41)
(37)
4. Loosen the screw on the plastic insert (41)
(36)
for the freezer door and remove the plas-
tic insert.
5. Screw down the plastic insert (39) on the
opposite side of the freezer door.
Attaching the hinges and doors
(39)
(7)
1. Unscrew the left screw foot (7).
(38)
2. Use the two screws (31) to attach the
lower hinge (32) on the left side and then
screw the screw foot (7) back in.
Use the screwdriver to tighten the screws
by just 2 to 3 turns, and then use the 8
mm spanner to tighten them fully.
(34)
(31)
(7)
(39)
