Replacing the
1.
control panel
Fig. 2 Removing control panel and unplugging
Installing the
To install, follow the LHSB installation instructions.
LHSB installation
set
Enabling the FS-
When ordering the licence code, name the serial number of the power source to be
CMT software
converted. The licence code, being delivered separately from the hardware, applies only
for this power source.
In addition to the CMT requirements, the FS-CMT software also contains the SFi function
(Spatter Free Ignition).
Important! The SFi function is only available with CMT welding programs.
To enable the FS-CMT software, proceed as follows:
Important! For further information on enabling the software, refer to the service module
software operating instructions.
1.
2.
3.
4.
5.
Loosen 3 screws on the control panel (2)
NOTE! When removing or installing the control panel (2) do not pinch, bend or
strain the ribbon cable (6).
ribbon cable
Connect power source to PC using RS 232/LocalNet interface
Start „service module" software
In the „service module" window,
-
select the converted power source from the node list
-
click „Licence manager"
Click „Enable" in the „Licence management" window
In the „Enable options" dialog box,
-
enter the licence code supplied
-
click „transmit code"
2.
Carefully remove the control panel (2)
(2)
3.
Unplug the ribbon cable (6) from the
socket (7)
On the CMT Remote control panel (2):
(6)
4.
Plug the ribbon cable (6) into the
socket (7)
5.
Carefully position the CMT Remote
control panel (2)
(7)
6.
Fit the CMT Remote control panel (2)
using 3 screws
