TECHNICAL DATA
Type
Production code
Voltage battery pack
No-load speed, 1st gear
No-load speed, 2nd gear
Impact range, 1st gear
Impact range, 2nd gear
Torque (5,0 Ah battery)
Drilling capacity in wood
with fl at bit
with auger bit
with hole saw
with selfeed bit
Drilling capacity in brick and tile
Wood screws (without pre-drilling)
Drill chuck range
Weight according EPTA-Procedure 01/2014 (2.0 Ah ... 12.0 Ah)
Recommended ambient operating temperature
Recommended battery types
Recommended charger
Noise information: Measured values determined according to
EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Always wear ear protectors!
Vibration information: Total vibration values (vector sum in the
three axes) determined according to EN 62841.
Vibration emission value a
/ Uncertainty K
h
Impact drilling into concrete
Drilling into metal
Screwing
WARNING!
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN
62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for diff erent
applications, with diff erent accessories or poorly maintained, the vibration and noise emission may diff er. This may signifi cantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or when it is
running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm, organization of work patterns.
WARNING
Read all safety warnings, instructions,
illustrations and specifi cations provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
DRILL SAFETY WARNINGS
Safety instructions for all operations
Hold the power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory or
fasteners may contact hidden wiring.
Cutting accessory or fasteners contacting a "live" wire may make
exposed metal parts of the power tool "live" and could give the
operator an electric shock.
Wear ear protectors when impact drilling. Exposure to noise can
cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of control
can cause personal injury.
Brace the tool properly before use. This tool produces a high
output torque and without properly bracing the tool during operation,
24
M18 FDD3
M18 FPD3
Cordless Drill Driver
Cordless percussion drill/driver
4813 05 01 XXXXXX MJJJJ 4813 14 01 XXXXXX MJJJJ
18 V
18 V
0-500 min
0-500 min
-1
0-2100 min
-1
0-2100 min
–
0-7800 min
–
0-33000 min
158,2 Nm
158,2 Nm
38 mm
38 mm
38 mm
38 mm
89 mm
89 mm
65 mm
65 mm
–
15,88 mm
16 mm
16 mm
1,6 – 13 mm
1,6 – 13 mm
1,9...3,1 kg
1,9...3,1 kg
-18...+50 °C
M18B...; M18HB...
M12-18...; M1418C6
95,78 dB(A) / 3 dB(A)
95,78 dB(A) / 3 dB(A)
106,78 dB(A) / 3 dB(A)
106,78 dB(A) / 3 dB(A)
–
11,3 m/s
1,85 m/s
/ 1,5 m/s
1,85 m/s
2
2
1,48 m/s
/ 1,5m/s
1,48 m/s
2
2
loss of control may occur resulting in personal injury.
Safety instructions when using long drill bits
Never operate at higher speed than the maximum speed rated
of the drill bit. At higher speeds, the bit is likely to bend if allowed to
rotate freely without contacting the workpiece, resulting the personal
injury.
Always start drilling at low speed and with the bit tip in contact
with the workpiece. At higher speeds, the bit is likely to bend if
allowed to rotate freely without contacting the workpiece, resulting
the personal injury.
Apply pressure only in direct line with the bit and do not apply
excessive pressure. Bits can bend causing breakage or loss of
control, resulting in personal injury.
ENGLISH
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is
recommended, such as dust mask, protective gloves, sturdy non-slip
footwear, helmet and ear defenders.
-1
WARNING To reduce the risk of injury in applications that produce
-1
a considerable amount of dust, use a Milwaukee dust extraction
-1
solution in accordance with the solution's operating instructions.
-1
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Wear a suitable dust protection mask.
Do not machine any materials that present a danger to health (e.g.
asbestos).
Switch the device off immediately if the insertion tool stalls! Do not
switch the device on again while the insertion tool is stalled, as
doing so could trigger a sudden recoil with a high reactive force.
Determine why the insertion tool stalled and rectify this, paying heed
to the safety instructions.
The possible causes may be:
• it is tilted in the workpiece to be machined
• it has pierced through the material to be machined
• the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.
WARNING! Danger of burns
• when changing tools
• when setting the device down
Chips and splinters must not be removed while the machine is
running.
When working in walls ceiling, or fl oor, take care to avoid electric
cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped
workpieces can cause severe injury and damage.
2
/ 1,5m/s
2
Remove the battery pack before starting any work on the machine.
/ 1,5m/s
2
2
Do not dispose of used battery packs in the household refuse or by
/ 1,5 m/s
2
2
burning them. Milwaukee Distributors off er to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System M18 chargers for charging System M18 battery
packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it off immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
ALWAYS USE A SIDE HANDLE when using a 9.0 Ah or higher
capacity battery pack; the output torque of some tools may increase.
If your drill/driver did not come with a side handle, use the spare part
side handle (see explosion drawing of the tool).
Do not insert the bit on the tool when the tool is running, and switch
is lock on status, the bit will be running and may hurt the user.
WARNING This device contains a lithium button/coin cell battery.
A new or used battery can cause severe internal burns and lead to
death in as little as 2 hours if swallowed or enters the body. Always
secure the battery cover. If it does not close securely, stop using the
device, remove the batteries, and keep it away from children. If you
think batteries may have been swallowed or entered the body, seek
immediate medical attention.
Warning! To reduce the risk of fi re, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fl uid or allow a fl uid to fl ow inside them. Corrosive or
conductive fl uids, such as seawater, certain industrial chemicals,
and bleach or bleach containing products, etc., can cause a short
circuit.
SPECIFIED CONDITIONS OF USE
M18FDD3: The battery drill/screwdriver may be used for drilling and
screwdriving for independent use away from mains supply.
M18 FPD3: The electronic battery percussion drill/screwdriver is
designed for drilling, percussion drilling, as well as screwdriving for
independent use away from mains supply.
Do not use this product in any other way as stated for normal use.
RESIDUAL RISK
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise in use and the operator should pay special
attention to avoid the following:
• Injury caused by vibration
Hold the product by designated handles and restrict working time
and exposure.
• Exposure to noise can cause hearing injury.
Wear ear protection and limit exposure.
• Injury due to fl ying debris
Wear eye protection, heavy long trousers, gloves and substancial
footwear at all times.
• Inhalation of toxic dusts.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Batteries which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery. Avoid extended exposure to heat or sunshine (risk of
overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the batteries have to be fully charged, after
used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery storage longer than 30 days:
Store the battery where the temperature is below 27°C and away
from moisture
Store the battery in a 30% - 50% charged condition
Every six months of storage, charge the battery as normal.
Battery protection for Li-Ion batteries
In extremely high torque, binding, stalling and short circuit situations
that cause high current draw, the tool will vibrate for about 5
seconds, the fuel gauge will fl ash,and then the tool will turn OFF. To
reset, release the trigger.
Under extreme circumstances, the internal temperature of the
battery could become too high. If this happens, the fuel gauge will
fl ash and the battery pack cool and then continue work.
Transport of Li-Ion batteries
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
• The user can transport the batteries by road without further
requirements.
• Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated
to prevent short circuit.
• Ensure that battery pack is secured against movement within
packaging.
• Do not transport batteries that are cracked or leak.
ENGLISH
25
