TECHNICAL DATA
Type
Production code
Battery voltage
Single impact energy
Frequency band(s) of Bluetooth
Radio-frequency power
Bluetooth version
No-load speed
Rate of percussion under load
Chuck neck diameter
Drilling capacity in concrete
Drilling capacity in steel
Drilling capacity in wood
Light core cutter in bricks and limestone
Weight according EPTA-Procedure 01/2014 (2.0 Ah ... 12.0 Ah)
Recommended ambient operating temperature
Recommended battery types
Recommended charger
Noise Information
Measured values determined according to EN
62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Wear ear protectors.
Vibration Information
Total vibration values (vector sum in the three axes) determined
according to EN
62841.
Vibration emission value a
/ Uncertainty K
h
Hammer-drilling in concrete (a
)
h,HD
Chiselling (a
)
h,Cheq
WARNING!
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN
62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for diff erent applications,
with diff erent accessories or poorly maintained, the vibration and noise emission may diff er. This may signifi cantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or when it is
running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm, organization of work patterns.
WARNING
Read all safety warnings, instructions,
illustrations and specifi cations provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
HAMMER SAFETY WARNINGS
Safety instructions for all operations
Wear ear protectors. Exposure to noise can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of control can
cause personal injury.
Hold the power tool by insulated gripping surfaces only,
when performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting accessory
contacting a „live" wire may make exposed metal parts of the power
tool „live" and could give the operator an electric shock.
Safety instructions when using long drill bits with rotary hammer
Always start drilling at low speed and with the bit tip in contact
with the workpiece. At higher speeds, the bit is likely to bend if
allowed to rotate freely without contacting the workpiece, resulting the
personal injury.
26
M18 ONEFHP
M18 ONEFHPX
Cordless Rotary Hammer
Cordless Rotary Hammer
4779 59 03 XXXXXX MJJJJ
4779 45 03 XXXXXX MJJJJ
18 V
18 V
5,0 J
5,0 J
2402-2480 MHz
2402-2480 MHz
1,8 dBm
1,8 dBm
4.2 BT signal mode
4.2 BT signal mode
0-800 min
-1
0-800 min
0-4600 min
0-4600 min
-1
54 mm
54 mm
32 mm
32 mm
13 mm
13 mm
30 mm
30 mm
75 mm
75 mm
4,2 kg ... 5,2 kg
4,4 kg ... 5,4 kg
-18...+50 °C
M18B...; M18HB...
M12-18...; M1418C6
98,1 dB(A) / 3 dB(A)
98,1 dB(A) / 3 dB(A)
106,1 dB(A) / 3 dB(A)
106,1 dB(A) / 3 dB(A)
8,46 m/s
2
/ 1,5 m/s
2
8,46 m/s
7,92 m/s
2
/ 1,5 m/s
2
7,92 m/s
Apply pressure only in direct line with the bit and do not apply
excessive pressure. Bits can bend causing breakage or loss of
control, resulting in personal injury.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes,
hard hat or hearing protection used for appropriate conditions will
reduce personal injuries.
The dust produced when using this tool may be harmful to health. Do
not inhale the dust. Wear a suitable dust protection mask.
Do not machine any materials that present a danger to health (e.g.
asbestos).
Switch the device off immediately if the insertion tool stalls! Do not
switch the device on again while the insertion tool is stalled, as doing
so could trigger a sudden recoil with a high reactive force. Determine
why the insertion tool stalled and rectify this, paying heed to the safety
instructions.
The possible causes may be:
• it is tilted in the workpiece to be machined
• it has pierced through the material to be machined
• the power tool is overloaded
ENGLISH
Do not reach into the machine while it is running.
The insertion tool is sharp-edged and can become hot during use.
WARNING! Danger of cuts and burns
- when handling the insertion tools
- when setting the device down.
Wear protective gloves when handling insertion tools.
Chips and splinters must not be removed while the machine is
running.
When working in walls ceiling, or fl oor, take care to avoid electric
cables and gas or waterpipes.
-1
Clamp your workpiece with a clamping device. Unclamped
-1
workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by
burning them. Milwaukee Distributors off er to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short circuit
risk).
Use only System M18 chargers for charging System M18 battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it off immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
WARNING This device contains a lithium button/coin cell
battery. A new or used battery can cause severe internal burns
and lead to death in as little as 2 hours if swal lowed or enters
the body. Always secure the battery cover. If it does not close
securely, stop using the device, remove the batteries, and keep it
away from children. If you think batteries may have been swallowed
2
/ 1,5 m/s
2
or entered the body, seek immediate medical attention.
2
/ 1,5 m/s
2
Warning! To reduce the risk of fi re, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fl uid or allow a fl uid to fl ow inside them. Corrosive or
conductive fl uids, such as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The battery rotary pneumatic hammer may be used for hammer
drilling and drilling in wood, metal as well as plastic for independent
use away from mains supply.
Do not use this product in any other way as stated for normal use.
RESIDUAL RISK
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise in use and the operator should pay special
attention to avoid the following:
• Injury caused by vibration.
Hold the product by designated handles and restrict working time
and exposure.
• Exposure to noise can cause hearing injury.
Wear ear protection and limit exposure.
• Injury due to fl ying debris
Wear eye protection, heavy long trousers and substancial footwear
at all times.
• Inhalation of toxic dusts.
ONE-KEY™
To learn more about the ONE-KEY functionality for this tool, please
reference the Quick Start guide included with this product or go to
www.milwaukeetool.com/one-key. To download the ONE-KEY app,
visit the App Store or Google Play from your smart device.
Also, when the product experiences ESD, the Bluetooth
communication will be disconnected. It needs to be reset manually to
recover.
ONE-KEY™ Indicator
Solid Blue
Wireless mode is active and ready to be
confi gured via the ONE-KEY™ app.
Blinking Blue
Tool is actively communicating with the ONE-
KEY™ app.
Blinking Red
Tool is in security lockout and can be unlocked
by the owner via the ONE-KEY™ app.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and
away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
Battery protection for Li-Ion Akkus
In extremely high torque, binding, stalling and short circuit situations
that cause high current draw, the tool will vibrate for about 5 seconds,
the fuel gauge will fl ash,and then the tool will turn OFF. To reset,
release the trigger.
Under extreme circumstances, the internal temperature of the battery
pack could raise too much. If this happens, the fuel gauge will fl ash
until the battery pack cooled down. After the lights go off , the work
may continue.
Transport of Lithium Batteries
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
• The user can transport the batteries by road without further requi-
rements.
• Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation and
transport are exclusively to be carried out by appropriately trained
persons and the process has to be accompanied by corresponding
experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated to
prevent short circuit.
• Ensure that battery pack is secured against movement within
packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice
ENGLISH
27
