Product Introduction

Product Introduction
Name and function of parts
5
1
3

What to do before operation

A
B

Operation Indication Lamps

On/Off
Filter Sign
Timer
Defrost Mode
Outdoor unit
operation
Sleep Mode
6 Convertible & Ceiling suspended Air Conditioner
6 7
4
2
4
1
1
: Lights up during the system operation.
: Lights up after 2400 hours from the time of first operating unit.
: Lights up during Timer operation.
: Lights up during Defrost Mode or Hot Start operation.(Heat pump type)
: Lights up during outdoor unit operation.
(Cooling type)
: Lights up during Sleep Mode Auto operation.(Option)
1: Indoor unit
2: Outdoor unit
3: Remote controller
4: Inlet air
5: Discharge air
6: Refrigerant piping, connection
7: Drain pipe
8: Ground wire
8
If your installation has a customized
2
control system, ask your LG dealer for
the operation that corresponds to your
system.
A: Pair system or simultaneous
B: Multi system
1: Unit with remote controller
1
2: Unit without remote controller (when
electric wire
wire to ground outdoor unit to
prevent electrical shocks.
operation system
used as simultaneous operation)
