Operating Instructions

Wireless Remote Controller

The controls will look like the following.
5
6
4
2
7
ON OFF
11
8
13
14

Operation Mode

Cooling Operation
Auto Operation
Soft dry Operation
Heating Operation
• Cooling Model( ), Heat Pump Model(
NOTE
To use the functions printed in blue at the bottom of the buttons press 2
button. Pressing the 2 F button activates the blue printed function of the respective button. To cancel the function
nd
press the 2nd F button again else it will automatically cancel if remains idle after 10 seconds.
❈ The actual product can be different from above contents depending upon model type.
8 Convertible & Ceiling suspended Air Conditioner
Signal transmitter
1
3
10
CANCEL
9
SET
AUTO CLEAN
12
15
Flip-up door
(opened)
)
1. ON/OFF BUTTON
Used to turn off/on the unit.
2. OPERATION MODE SELECTION BUTTON
Used to select the operation mode.
3. ROOM TEMPERATURE SETTING BUTTONS
Used to select the room temperature.
4. INDOOR FAN SPEED SELECTOR BUTTON
Used to select fan speed in four steps
low, medium, high and CHAOS.
5. JET COOL BUTTON
Used to start or stop the speed cooling.
(It operates fan in super high speed in cooling mode)
6. CHAOS SWING BUTTON
Used to stop or start louver movement and set the
desired up/down airflow direction.
7. ON/OFF TIMER BUTTONS
Used to set the time of starting and stopping
operation.
8. TIME SETTING BUTTONS
Used to adjust the time.
9. TIMER SET/CANCEL BUTTON
Used to set and to cancel the timer operation.
10. SLEEP MODE AUTO BUTTON
Used to set sleep mode auto operation.
11. AIR CIRCULATION BUTTON
Used to circulate the room air without cooling or
heating.
12. ROOM TEMPERATURE CHECKING BUTTON
Used to check the room temperature.
13. PLASMA BUTTON(OPTIONAL)
Used to start or stop the plasma-purification
function.
14. RESET BUTTON
Used prior to resetting time.
15. 2nd F BUTTON
Used prior to using modes printed in blue at the
bottom of buttons.
F button first and then the required function
nd
