CONTROLS
JR SODCUTTER CONTROLS
Blade (H) and Wheel (J) Shifter Handles : Engage
or disengage blade for cutting and gears for
driving Sodcutter.
MOVING THE JR SODCUTTER
To move unit without running blade :
1. Place blade shifter handle H in "disengaged"
position (handle will point straight out from unit).
2. Set engine speed at slow speed.
3. Engage drive shifter handle.
4. Depress operator presence control.
5. Engage operator presence control.
6. Engage clutch control lever.
7. Adjust throttle to desired walking speed.
GB-6
GEAR GEAR
CASE CASE
"DISENGAGED"
SHIFTER HANDLE
To move unit without running engine :
1. Put drive shifter handle and clutch control lever
in "Disengaged" position.
To transport the unit :
1. When transporting unit on trailer or truck, shut
fuel valve "OFF" beneath fuel tank.
Jr.
Sodcutter
"ENGAGED"
SHIFTER
