Parameterization via TRWinProg

8 Parameterization via TRWinProg

8.1 Basic values

8.1.1 Counting direction

Display
up
down

8.1.2 Scaling parameters

The scaling parameters can be used to change the physical resolution of the
measuring system. The position value output is calculated with a zero point correction,
count direction and the code set. The measuring system does not support decimal
numbers or numbers of revolutions (gearbox function) deviating from exponents of 2.

8.1.2.1 Singleturn

Defines how many steps the measuring system outputs for one revolution of the
measuring system shaft.
Selection
8 Bit
9 Bit
10 Bit
11 Bit
12 Bit
 TR-Electronic GmbH 2009, All Rights Reserved
Page 52 of 56
Description
Measuring system position increasing clockwise
(view onto the shaft)
Measuring system position decreasing clockwise
(view onto the shaft)
Description
≙ 256 steps per revolution
≙ 512 steps per revolution
≙ 1024 steps per revolution
≙ 2048 steps per revolution
≙ 4096 steps per revolution
