RF TGM SW868 / RF TGM SW915
//
Montage- und Anschlussanleitung / Funkschalter
Mounting and wiring instructions / Wireless switch
Instructions de montage et de câblage / Interrupteur sans fil
Istruzioni di montaggio e collegamento / Interruttore wireless
Instruções de montagem e instalação / Interruptor sem fio
English
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
Device, battery, mounting and wiring instructions, carton.
Intended use
The one-channel wireless switch is used to switch electrical loads
via radio transmission. The receiver must support the protocol of the
sWave® wireless technology.

Mounting and wiring

Mount the device on an even surface. Install the device according to
the mounting and wiring instructions of the receiver. The wireless
range depends heavily on the local conditions. Conductive materials
may strongly affect the radio signal. This also includes thin foils, e.g.
aluminium laminations on insulation materials.
Assignment of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz
Design of wireless range
The radio signal is attenuated on the way from the transmitter to the
receiver. In addition, the radio signal is influenced by obstacles. The
degree of attenuation depends on the material of the obstacle. The fol-
lowing tables serve as a guide.
Location According to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Location
in free field (SW868/915/917)
in free field (SW922)
indoors (SW868/915/917)
indoors (SW922)

Radio operation

The transmission of a switching command from the transmitter to the
receiver takes about 80 to 100 ms, based on the sWave® data trans-
mission. The switching signal of a transmitter must not be generated
in a shorter time interval. Otherwise this signal will be suppressed.
Maintenance and cleaning
.steute recommends routine maintenance as follows:
1. Remove all dirt particles: Clean enclosure on the outside only.
Clean device in accordance with IP protection class. Clean with
a soft cloth and water or a mild detergent.
Do not clean using compressed air.
2. Replace damaged parts.
3. Test the function.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately. Dispose of possibly contained
batteries correctly.
N.B.
Subject to technical modifications. Reconstruction and alterations to
the device are not allowed. It is the responsibility of the manufacturer
of a plant or machine to guarantee the correct general function.
2 / 12
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
150 m
40 m
20 m
