English

Mounting and wiring

Mount the device on an even surface. Install the device according to
the mounting and wiring instructions of the receiver. The wireless
range depends heavily on the local conditions. Conductive materials
may strongly affect the radio signal. This also includes thin foils, e.g.
aluminium laminations on insulation materials.
Allocation of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz

External devices

The sensor/switch connection is evident at the M12 plug-in connector.
At this plug-in connector the inductive sensors RF IS M8/M12/M18- or
M30 or other mechanical switches with gold-plated contacts can be
connected. Therefore, the connecting cable Material No. 1189960 can
be used that is avai-lable as accessory. The mechanical switches must
be equipped with a NO/NC contact. It must be connected to plus (pin 1)
and to the entry (pin 4). To connect external devices (sensors or
switches): see section »Connecting external devices«. When installing
the external device, follow its installation instructions.
Connectable devices:
Device
0.3 m
RF IS M8 nb-ST
RF IS M12 nb-ST
RF IS M18 nb-ST
RF IS M30 nb-ST
RF RC 20 1S-ST 1335490
connecting cable,
open wire ends
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Place of use according to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Material No. (Cable length)
0.5 m 1 m 2 m
1470040 1373082 1305745
1228522 1356467 1189974
1261564 on request 1189975
1260490 1228548 1189976
1215497
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
in free field (SW868/915/917)
in free field (SW922)
indoors (SW868/915/917)
indoors (SW922)
Field strength meter for range test:
Transmitter Device
SW868 swView 868 MHz
SW915 swView 915 MHz
SW917/SW922

Radio operation

To avoid too fast actuation, there is, by default, a delay time of 1 s when
processing one switching command from transmitter to receiver (if the
radio interface is unoccupied and there are no repeat telegrams). The
switching signal from a transmitter may not be generated at a shorter
interval, otherwise the signal will be suppressed. The preset delay
time of 1 s can be adjusted from min. 0.5 s to max. 31 s (configurable
on the Sensor Bridge Interface under: »Groups«, »Timing«).
Safety
Do not use the device in connection with other devices whose direct or
indirect purpose is to ensure life or health, or whose operation may
pose a threat to humans, animals or material assets.
N.B.
Subject to technical modifications. Reconstruction and alterations to
the device are not allowed. The described products were developed in
order to assume safety functions as part of an entire plant or machine.
It is the responsibility of the manufacturer of a plant or machine to
guarantee the correct general function. steute does not assume any li-
ability for recommendations made or implied by this description. New
claims for guarantee, warranty or liability cannot be hereby derived
beyond the general terms and conditions of delivery.
3 / 20
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
150 m
40 m
20 m
Material No.
1190393
1221794
on request
