Endress+Hauser levelflex M FMP 41 C Bedienungsanleitung Seite 12

XA 262F-A
Uo ≤ 17.5 V
Certified
Io ≤ 500 mA
associated
Po ≤ 5.5 W
apparatus
Category
Type of protection
Max. operating pressure
Process temperature
Housing F12
Option e.g. HAW 262 Z
HAW 562 Z
Remote display
Service interface
Please observe the following installation instructions:
1.) Install in accordance with the manufacturer's specifications and the valid standards and regulations.
- Do not operate the level sensor outside of the electrical, thermal and mechanical parameters
2.) The intrinsically-safe input power circuit of the Levelflex M is isolated from ground potential and has a dielectric strength of at
least 500 Vrms with respect to it.
2.1 For grounding the screen, see figure 3 and figure 4.
3.) The relationship between the permitted ambient temperature for the electronics housing, dependent on the range of
application, and the temperature classes is shown in the tables (Tab. 1 and Tab. 3).
4.) After aligning (rotating) the housing, retighten the fixing screw (see Operating Instructions).
5.) Use connecting cable for continuous duty temperature ≥ Ta + 5 K
6a.) Install the device to exclude any mechanical damage or friction during the application. Pay particular attention to flow condi-
tions and fittings.
6b.) Special conditions (X marking)
The probes (rod and rope version) of the level radar Levelflex M type FMP 41C-....... have plastic surfaces, which can become
electrostatically charged.
For areas requiring instruments of category II 1 G or II 2 G, the electrostatic limits have to be observed.
Category Admissible transmitted charge Q in nC
Dusts
1
2
3
For the level radar Levelflex M type FMP 41C-.... this results in the following relationship:
Area/Components with plastic
surfaces
flange cladding
rod
rope
rope weight
Measures:
Instruments with flange cladding (plastic) may be installed in areas requiring instruments of category II 1 G or II 2 G without
further protective measures, if charging of the flange cladding is prevented by the installation (e.g. no exposed plastic
surfaces or installation in metallic connection parts/nozzles).
4
Uo ≤ 24 V
or
Io ≤ 250 mA
Po ≤ 1.2 W
II 1/2 G or II 2 G
EEx ia IIC T6..T3
dependent on the probe
dependent on the probe
-40 °C ≤ Tu ≤ 80 °C
intrinsically-safe power
supply and signal circuit
e.g. FHX40
Commubox FXA 193 with associated ToF
cable
IIA IIB
60 30
60 30
no limit
measured transmitted charge Q
in nC (Test Report)
< 75
< 30
< 10
< 30
Profibus PA or Foundation Fieldbus
FISCO model
[EEx ia] IIC or [EEx ib] IIC
Probe in Zone 0 and housing Zone 1 or probe and housing in Zone 1
KEMA 04 ATEX 1129 X
optionally with or without VU 331 display and operating module
e.g. route armoured hose up to the housing
KEMA 02ATEX1203
IIC
10
10
X-marking required for the following material groups
IIA
--
--
--
observe associated Safety Instructions
(XA193F-.)
observe associated Safety Instructions
(XA077D)
IIB IIC
-- IIC
-- --
-- IIC
