3.

INSTALLATION ON THE HELMET

Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 17.4).
The installation video can be found in the support section at www.n-com.it
3.1.

Battery connection

Open the e-box (Fig. 1).
•
Connect the battery to the port (Fig. 2), taking care to insert it correctly. If necessary use the
•
provided flat head screwdriver to insert the battery connector fully into the port.
Close the e-box (Fig. 3).
•
Fig. 1
3.2.

Initial steps

Before you install the B602 system on the helmet, make sure it turns on properly. Press the "n"
•
key for about 2 seconds, until the blue LED on the keypad lights up and you hear a beep in the
headset. Proceed with the installation.
Remove the cheek padding (see helmet instructions).
•
Remove the helmet edge gasket using the special tool (Fig. 4).
•
Completely remove the gasket as shown in Fig. 4; by doing so you also remove the padding.
•
Remove the "N-Com" plugs found at the back of the shell gasket and on the left side of the
•
helmet.
Fig. 4
Fig. 2
Fig. 4B – ONLY FOR N87, N80-8, N100-5 HELMETS
Fig. 3
7
