7.7 CHECK THE SEAL ON THE FIRE DOOR
Check the door seal for leaks and damage at least twice a year; the first time before
the season starts. If necessary, have the door seal replaced by a Qlima-approved
technician. Only use original Qlima spare parts.
7.8 CLEANING THE PELLET HOPPER AND AUGER
Clean the pellet hopper and auger once a month.
1.
2.
3.
7.9 CLEANING THE PELLET SUPPLY PIPE
Clean the pellet supply pipe once a week with a stiff round brush (figure 36). The
pellet supply pipe is located in the stove's combustion chamber. Creosote can build
up in the supply pipe and contaminate it to such an extent that it can get blocked
by pellets.
4
164
Tip for replacing the clamping strips: First place the bottom of the
clamping strip between the front and back plates (see Figure 34).
Make sure that the bottom remains properly in place when the entire
clamping strip is pressed between the two plates.
If the clamping strips are difficult to fit, check that the back plate is
properly mounted in its place.
Empty the pellet hopper.
Clean the pellet hopper and the visible part of the auger with a vacuum
cleaner (figure 35).
Fill the hopper with pellets.
