Transmission principle

The data is transmitted from the PC to the manual programming device or vice versa via the serial
interface COM1 or COM2�
The data is transmitted from the manual programming device to the respective time switch via a
infrared interface or read out from the time switch by the manual programming device�
The same method is used to transmit the switching programs from time switch to time switch�
16
IR interface
Manual programming
device
PC interface
