the pressure port (5) of the pump. To protect the pump from damage caused by pressure surges it is
advisable to equip the pressure line with a check valve (6) to be installed directly downstream the
pump outlet.
Also, to facilitate maintenance work, it is recommendable to install a shut-off cock (7) after the pump
and check valve. This is a useful feature since it can be closed when the pump has to be dismantled
and will thus prevent the pressure line from draining to empty.
5.4. Stationary installation
With regard to the electrical connection in the case of stationary installation, please
ensure an adequate visibility and accessibility of the plug.
For stationary installation, please fasten the pump on a suitable, solid surface. To reduce vibration, it
is recommended to apply an anti-vibration material - for instance a rubble layer - between the pump
and the installation surface.
Use the baseplate (13) as a template for marking out the drill holes. Place the unit in the required
position insert a punch or pin through the holes in the baseplate to mark the position of the drill holes.
Put the device aside, then use a suitable drill for pre-drilling the four holes. Place the device back into
the desired position, then fasten it there using suitable screws and washers.
5.5. Using the pump for garden ponds and similar places
Operating the pump next to garden ponds and similar places is generally only
admissible if no persons are in contact with the water.
If the pump is used for garden ponds and similar places it has to be operated using a residual current
circuit-breaker (FI switch) with a nominal trigger current of ≤ 30mA (DIN VDE 0100-702 and 0100-
738). Please ask your electrical services provider whether your installation site complies with this
condition.
The pump must not be used in such locations unless it is set up firmly and flood-proof, a minimum
distance of two metres away from the border of the water body and secured against falling into the
water by a solid holding device. For this purpose the device is to be bolted down firmly to the ground
at the fastening points provided (please refer to the chapter titled "Stationary installation").

6. Electrical conection

The unit is equipped with a mains connection cable and a mains plug. It must only be replaced by
qualified staff to avoid any danger. Please do not use the mains connection cable to carry the pump,
and do not use this cable to pull off the plug from the socket, either. Protect the mains connection
cable and mains plug from heat, oil or sharp edges.
The values stated in the technical details have to correspond to the mains voltage.
The person responsible for the installation has to make sure that the electrical
connection is earthed in compliance with the applicable standards.
The electrical connection has to be equipped with a highly sensitive residual current
circuit-breaker (FI switch): ∆ = 30 mA (DIN VDE 0100-739).
Only use an extension cable with a cable section (3 x 1.0 mm²) and rubber sheath
which at least corresponds to that of the unit's own connection cable (see "Technical
data", cable type) and which is labelled with the relevant abbreviation according to
the VDE (German Association for Electrical, Electronic & Information Technologies).
The mains plug and other connections must be splashproof.
