7 Refuelling the Lawn Mower

NOTICE
■ The lawn mower does not contain any engine
oil on delivery. Starting the engine with no or
too little engine oil may damage the lawn
mower.
► Always check the engine oil level before
starting and if necessary top up.
► Add the engine oil as described in the engine
instruction manual.
7 Refuelling the Lawn Mower
7.1 Refuelling the Lawn Mower
NOTICE
■ The lawn mower may be damaged if the cor‐
rect fuel is not used.
► See the engine instruction manual.
► Stop the engine.
► Place the lawn mower on a level surface.
► Clean the area around the fuel tank cap with a
damp cloth.
► Turn fuel tank cap (1) anti-clockwise until it
can be removed.
► Remove the fuel tank cap.
► Add fuel using a suitable funnel, stopping at
least 15 mm short of the fuel tank brim.
► Place the fuel tank cap on the fuel tank.
► Turn the fuel tank cap clockwise and tighten
firmly by hand.
The fuel tank is sealed.
8 Adjusting the Lawn Mower
for the User
8.1 Folding Up and Adjusting the
Handlebar
► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
0478-111-9657-B
► Loosen nuts (1) on the left and right.
► Fold up handlebar (2), ensuring that cables (3)
are not trapped.
► Tighten nuts (1) on the left and right.
Handlebar (2) is firmly attached to the lawn
mower.
► Press control bar for mowing (4) to handle‐
bar (2) and hold.
► Slowly pull starter handle (5) in the direction of
starter rope guide (6).
► Hook starter handle (5) into starter rope
guide (6).
► Release control bar for mowing (4).
► Re-attach the spark plug socket.
