nOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as a flashlight.
Performing an Application (Fig. A)

WARNING: To reduce the risk of personal injury,
ALWAYS ensure workpiece is anchored or clamped firmly.

WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
of rotation.
Prior to performing work:
• Set the speed selector
6
• Install the appropriate bit or accessory into the chuck. Refer
to Installing a Bit or Accessory into a Keyless Chuck.

WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol, etc.).
• Do not mix or stir flammable liquids
labeled accordingly.
Screwdriving
Your tool has a clutch with adjustable torque for driving
and removing a wide array of fastener shapes and sizes. The
numbers on the mode selection collar
torque range for screwdriving. The higher the number on the
collar, the higher the torque and the larger the fastener which
can be driven.
1. Turn the mode selection collar
Refer to Mode Selection.
2. Pull the trigger switch applying pressure in a straight line
with the bit until the fastener is seated at the desired depth
in the workpiece.
Recommendations for screwdriving
• Start with lower torque settings, then advance to higher
torque settings to avoid damage to the workpiece
or fastener.
• Make some practice runs in scrap or on unseen areas of the
workpiece to determine the proper position of the mode
selection collar.
Drilling
1. Turn the mode selection collar
to Mode Selection.
2. Place drill bit in contact with the workpiece.
nOTE: Use sharp drill bit only.
3. Pull the trigger applying pressure in a straight line with the
bit until it reaches the desired depth.

WARNING: Drill may stall if overloaded causing a sudden
twist. Always expect the stall. Grip the drill firmly to control
the twisting action and avoid injury.
4. Keep the motor running when pulling the bit back out of a
drilled hole to prevent jamming.
Recommendations for Drilling
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect the bit.
. Refer to Speed Selection.
5 are used to set a
5 to the desired position.
5 to the drill symbol. Refer
IF THE DRILL sTaLLs:
•
RELEasE TRIGGER sWITcH IMMEDIaTELY, remove
-
drill bit from work, and determine cause of stalling.
DO nOT DEPREss TRIGGER sWITcH On anD OFF
-
In an aTTEMPT TO sTaRT a sTaLLED DRILL—THIs
can DaMaGE THE DRILL.
To minimize stalling or breaking through the material,
-
reduce pressure on drill and ease the bit through the last
fractional part of the hole.
• Large holes (7.9 mm to 12.7 mm) in steel can be made
easier if a pilot hole (4 mm to 4.8 mm) is drilled first.
• If drilling thin material or material that is prone to splinter,
use a wood "back‑up" block to prevent damage to
the work piece.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
The charger and battery pack are not serviceable.
C
Lubrication
Your power tool requires no additional lubrication.
D
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.
Optional Accessories

WARNING: Since accessories, other than those offered
by D WALT, have not been tested with this product, use
e
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
accessories should be used with this product.
Consult your dealer for further information on the
appropriate accessories.
