EnGLIsH
Installing a Bit or Accessory into a
Keyless Chuck (Fig. E)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changing acces sories.

WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personal injury.
Your tool features a keyless chuck with one rotating sleeve
one‑handed operation of the chuck. To insert a drill bit or other
accessory, follow these steps.
1. Turn tool off and remove battery pack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desired accessory.
3. Insert the accessory about 19 mm into the chuck and
tighten securely by rotating the chuck sleeve clockwise with
one hand while holding the tool with the other. Your tool is
equipped with an automatic spindle lock mechanism. This
allows you to open and close the chuck with one hand.
Be sure to tighten chuck with one hand on the chuck sleeve and
one hand holding the tool for maximum tightness.
To release the accessory, repeat steps 1 and 2 above.
Installing a Bit or Accessory with No Attachment
(Fig. E)
You can use your tool without installing an attachment.
Insert a hex bit directly into the spindle
place magnetically.
Speed Selection (Fig. A)
The tool features two speed settings for greater versatility
nOTE: Do not change speeds when the tool is running.
Always allow the tool to come to a complete stop before
changing speed.
1. To select speed 1 (high torque setting), turn the tool off and
permit it to stop. Slide the speed selector
from the chuck).
2. To select speed 2 (high speed setting), turn the tool off and
permit it to stop. Slide the speed selector
the chuck).
If the tool does not change speeds, confirm that the speed
selection switch is completely engaged in the forward or
back position.
Mode Selection (Fig. A)
The mode selection collar
5
operating mode depending upon the planned application.
To select, rotate the collar until the desired symbol aligns with
the arrow.
34
19 . It is held in
6 back (away
forward (toward
6
can be used to select the correct
symbol
1–15
Variable Speed Trigger and Forward/Reverse
Control Button (Fig. A)
The tool is turned on and off by pulling and releasing the
variable speed trigger switch
depressed, the higher the speed of the tool. Your tool is
equipped with a brake. The chuck will stop as soon as the
for
14
trigger switch is fully released.
A forward/reverse control button
direction of the tool and also serves as a lock‑off button.
• To select forward rotation (clockwise), release the trigger
and depress the forward/reverse control button on the right
side of the tool.
• To select reverse (counterclockwise), depress the forward/
reverse control button on the left side of the tool.
nOTE: The centre position of the control button locks the tool
in the off position. When changing the position of the control
button, be sure the trigger is released.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
nOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate a problem.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Proper Hand Position (Fig. F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main handle
and one hand on the battery pack.
Worklight (Fig. A)
There is a worklight
worklight is activated when the trigger switch is depressed.
When the trigger is released, the worklight will stay illuminated
for up to 20 seconds.
Mode
Drilling
Screwdriving (higher number = greater torque)
3 . The farther the trigger is
determines the rotational
4
7 located on the foot of the tool. The
17
