FlexiDome
VF
| Installation Manual
Main menu
Function
Selection
LEVEL
-15 - 0 - +15
SHUT/AGC Select submenu
BLC
ON, OFF
COLOR*
ATW
ATB HOLD
Select submenu
SYNC
LINE LOCK
INTERNAL
VPHASE
0, 2, ... 358°
EXIT
* Only in color version of camera. If a color camera is in monochrome
mode, all color related menu items are disabled and cannot be accessed.
Shutter/AGC submenu
Function
Selection
SHUTTER
AES, FL
AGC
ON/OFF
AUTOBLACK ON/OFF
Bosch Security Systems | 2005-11 | V1.0
All manuals and user guides at all-guides.com
Description
Adjusts the video output level
Select to access the Shutter / Automatic Gain
Control menu
When ON, the video level is optimized for the
selected area of the image. Parts outside this area
may be underexposed or overexposed (this is
normal).
Select to access the color menu.
Select LINE LOCK to synchronize with the power
supply frequency. Select INTERNAL for use with
internal synchronization (automatically selected
with DC supply).
Adjusts the vertical phase offset (when in LINE
LOCK mode and a valid power supply frequency
is detected).
Exit the menu
Description
• AES - auto-shutter - the camera automatically
sets the optimum shutter speed
• FL - flickerless mode avoids interference from
light sources (recommended for use with video
iris or DC iris lenses only)
Automatic gain control
Autoblack automatically increases the visibility of
details.
EN | 19
