Do not expose the device to aggressive acids or bases.
Do not use the device in places where its use is prohibited.
Turn off the device in clinics or other medical facilities.
Always keep a safety distance of at least 15 cm between the device and a pacemaker or
hearing aid. The device can affect the functioning of medical devices such as pacemakers and
hearing aids.
When using the device while driving a motor vehicle, be sure to comply with applicable
national laws.
WHEN USING EARPHONES OR HEADSETS
First set the volume control on the device to 50 % of the maximum volume.
Gradually adjust the volume.
DEVICE OVERVIEW/FUNCTIONS
1
EARPHONE JACK
2
FUNCTION KEY: Optional function (can be assigned via apps used).
3
STATUS LED: Display for notifications and charging status.
4
POWER KEY: A long press switches the device on/off. A short press switches the stand-
by mode on/off.
5
FUNCTION KEY: Optional function (can be assigned via apps used).
6
LOUDNESS CONTROL: Volume up/Volume down.
7
CURRENT APPLICATION: Shows all open applications.
8
HOME KEY: Switch to the main screen.
9
BACK KEY: Go to the previous screen.
10
MICROPHONE
11
LOUDSPEAKER
12
BACK CAMERA
13
MICROPHONE: Noise cancelling microphone/hands-free microphone.
14
LED FLASH
15
CHARGING CONTACTS
16
USB INTERFACE: Connection for the Type C USB Cable or for connection to other
devices. Also see sections "Charging" and "Connecting approved accessories".
17
BELT CLIP
PREPARATION
Loosen the screws on the battery compartment using the Screwdriver provided.
Remove the battery compartment cover.
Insert the SIM card into the slot. The device has two slots for one SIM card each. The slots are
marked „SIM 1" and „SIM 2".
Optional: Insert the microSD card into the slot provided. The device has a slot for a microSD
card up to 128 GB. The slot is marked "microSD".
(see illustration on page 2)
