3. Layout, Connections & LED's
3.3 Connections
Serial:
RS-232
RS-422/485
1 2 3 4
Ethernet:
12345678
+12V to +48V DC socket:
+
-
+12V to +48V T-Block:
+V
-V
enclosure earth
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
Serial RJ45 Port
Pin RS232 RS422 RS485 Pin RS232 RS422 RS485
1
TxD+ Data+
2
RxD
TxD-
3
TxD
RxD+
4
RxD-
RJ45 Port
Pin
Signal
1
BI_DA+
2
BI_DA-
3
BI_DB+
ATTENTION!
Only for use with the power supply unit included in the scope
of delivery or another compliant power supply unit!
ATTENTION!
Never connect power to the enclosure earth, this can destroy
your hardware!
18
5
Data-
6
GND
7
RTS
8
CTS
Pin
Signal
Pin
4
BI_DC+
5
BI_DC-
6
BI_DB-
EX-61001
GND
GND
Signal
7
BI_DD+
8
BI_DD-
