Master/slave operation via QuickDMX
1 Set the master device and each slave device to the same transmission channel using the function SET
2.4G. Thus, the spotlights are paired.
2 Set the master unit to the desired operating mode and all slave units to SLAVE mode. The devices will
now operate in synchronously.
Key lock
You can lock the operating buttons to e.g. prevent menu tampering. If the menu option PASSCODE is
enabled, the buttons will be automatically locked from the last command. In order to disable the key lock
function, press these buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
QuickDMX transmission channel/Wireless 2.4G
You can use the SET 2.4G menu to set the wireless transmission channel for QuickDMX operation. Use the
buttons UP and DOWN to choose wireless transmission channel with ON (QuickDMX enabled) or OFF
(QuickDMX disabled). Confirm with the ENTER button.
Please refer to the corresponding chapter for further explanation.

Remote control IR-7

The device must be activated for remote control. For this, set menu item INFRARED to ON. When actuating
a button, always direct the remote control towards the sensor. There must be no obstacles between remote
control and the sensor. In DMX and slave mode, the remote control functions are deactivated.
Notes:
• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the
foil from the battery support on the rear side of the remote control. Otherwise operation of the remote
control is not possible.
• If the range of the remote control decreases, replace the battery. For this purpose,
on the rear side of the remote control press the small bar with the groove to the
right and at the same time remove the battery support. For operation, one 3 V
button cell type CR 2025 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
• Remove the battery from the remote control as a precaution if the device is not used for a longer period of
time.
Button Function
BLACKOUT LEDs off
Automatic mode
AUTO
program selection with (+)/(‒)
Strobe effect for automatic mode
STROBE
flash rate setting with (+)/(‒)
Running speed in
SPEED
setting with (+)/(‒)
Microphone sensitivity
SENSITIVITY
setting with (+)/(‒)
DMX DMX mode on/off
MANUAL White select: press MANUAL and W
Fade in/out
FADE
speed setting with (+)/(‒)
Total brightness
1-9
(1 = dark, 9 = bright)
28/32
automatic mode
