DESCRIPTION OF THE DEVICE

3
2
1
(1) Mounting brackets
(2) 200 W WW COB LED
(3) Infrared sensor for the remotel control
(4) Fixation screw
(5) DMX input
(6) Antenna for QuickDMX
Note: When connected correctly, the power and DMX sockets are protected from spraying water according
to IP65. When not in use, make absolutely sure to close the sockets with the rubber sealing caps.
6
5
4
9
(7) LC display with operating buttons
(8) DMX output
(9) Pressure compensation plug
(10) Power in
(11) Safety eyelet
(12) Power out
21/32
7
10 11 12
00138977, Version 1.0
